Mitus-C

Minebea Intec

For Inspection of Packaged and Unpackaged Products

・Extensive Variety: Over 300 coil sizes available to fit your production line.
・Customizable Reject Systems: Choose the optimal rejection method based on the shape and weight of your products.
・Signal Visualization: Intuitive operation via a 5.7-inch color touch panel.

Features

・20% improvement in sensibility compared to Vitus (compared to our previous model)
・Various coil sizes
・Multi-frequency technology
・Tracking technology
・Automatic learn function
・Registers up to 200 products
・Protection class IP65(Option：IP69k)

scroll

Specification name	Specification contents
Coil Size(W)	175㎜~2,750㎜
Coil Size(H)	30㎜~600㎜
Belt width	100㎜~750㎜
Product height	100㎜~600㎜
Belt speed	0.11m/s～1.92m/2
Reject method	Conveyor stop, discharge equipment (Option)
Transport amount	25kg～50kg
Number of items in memory	50 (Option up to 200)
Display method	5.7inch color touch screen
Power supply	Search coil: :AC85～264V(±10%/-15%);47～63Hz (Single-phase) Belt conveyor::1)230/400V(+10%/-15%);50/60Hz (Three-phase) 2)AC230V(+10%/-15%);50/60Hz (Single-Phase)
Power consumption	500W
Operating environment	-10℃~+55℃
Product temperature	-30℃~+55℃
Protection class	IP65(Option:IP69k)
Data　interface	SPC@Enterprise / RS232,422 / Profibus / Remote control / OPC DA and OPC UA
Options	USB print, Signal light,Buzzer etc.

scroll

Parts No.

Catalog data

Mitus-C Mitus_.pdf
・Multi-frequency
technologyDetection sensitivity increases according to the search coil frequency, along with product effect. Vistus series realizes high sensitivity for any product, through automatic configuration of the optimal frequency for the product within a wide frequency range.
・Automatic learn function
The 5.7” color touch panel makes operation simple, enabling optimal setting to be made automatically just by running the product through a few times in accordance with the screen instruction.
・Day-to-day management
Sensitivity testing can be performed as needed, when switching between products, by inspection quality, or at fixed intervals. Test results and setting change logs are saved for confirmation at any time.
・Cleanliness
Stainless steel specifications conform to IP65 as standard. IP69k conforming products are also available as an option, following high-temperature/high-pressure water washing.
