CK01 Series
１．Achieves a maximum rated current of 7A, making it suitable for use in power circuits
２．Supports branching relay, allowing for branching of electrical circuits
３．Features a robust lock structure positioned on both sides
【Model Description】
()・・・ Number of pins
＊・・・ Product specification
-
-
Parts No. CK01A6-04*A Pin Count 4 Pich
[mm]4.40 Waterproof Grade IP67 Mounting Method/
Wiring methodIDC Current Rating
[A/Pin]0.3sq:6.00 MAX
1.25sq:9.00 MAXDielectric Withstanding
Voltage1,000V A.C.(r.m.s) for a minute Operating Temparature
Min
[deg.C]-40 Operating Temparature
Max
[deg.C]105 Cable Jacket Diameter
[Φ]＊=N:Small Size Φ1.30～1.60
-
-
The product information in this data is for reference only.
This is subject to change without notice.
Contact our sales staff for further information before considering or ordering any of our products.
Please request the Engineering Drawing for the most current and accurate design information.
