08038DA

Server(Telecom)

It is the latest design for servers and communication devices that realize high rotation, high air volume, and high static pressure.

General Specifications

Motor Protection:Auto Restart / Polarity Protection
Insulation Resistance:10M ohm or over with a DC500V Megger
Dielectric Withstand Voltage:AC700V 1s
Allowable Ambient Temperature Range :-10deg.C - +60deg.C (Operating)
-30deg.C - +60deg.C (Storage)
non-condensing environment
Please contact us for the spec beyond the temperature range here.

Click the arrow icon in the table below to switch from ascending to descending order.

scroll

Model	Product No	Nominal Voltage [V]	Operating Voltage lower limit [V]	Operating Voltage upper limit [V]	Current [A]	Input Power [W]	Speed [min-1]	Max. Air Flow [m3/min]	Max. Air Flow [CFM]	Max. Static Pressure [Pa]	Max. Static Pressure [In H2O]	Noise [dB]	Mass [g]
08038DA-12N-EU-D0	D0	12	10.8	13.2	1.45	17.40	8500	2.35	83.00	480.0	1.93	63.0	245.0
08038DA-12R-EK-D0	D0	12	10.8	13.2	3.30	39.60	12000	3.36	118.60	910.0	3.65	70.0	245.0

Rotation: Clockwise as seen from the label side
Airflow Outlet: Label side
*1: Average Values in Free Air

Outline

Panel Out-cuts

Characteristic Curves

40deg.C 70,000 Hours : 08038DA-12N-EU *Failure Rate 10% (L10 Life)
40deg.C 60,000 Hours : 08038DA-12R-EK *Failure Rate 10% (L10 Life)
Casing:Plastic (Black) UL94V-0
Impeller:Plastic (Black) UL94V-0
Bearing:Ball
BearingLead Wire:UL10368 AWG22 +: Red, -: Black
* Variable speed type is also available.
Please inquire regarding the other requirements.
