SG24M

Click the arrow icon in the table below to switch from ascending to descending order.

scroll

Model	Rated Voltage [V]	No load speed [min-1]	No Load Current [mA]	Rated Load [gf･cm]	Rated Load [mN・m]	Rated Load Speed [min-1]	Rated Load Current [mA]	Max Rated Load Torque [gf･cm]	Max Rated Load Torque [mN・m]	Starting Torque [gf･cm]	Starting Torque [mN・m]	Gear Ratio	Gear Step	Gear Box L1 [mm]	Weight [g]
SG24M1CTC	12.0	124	54.0	408.00	40.00	92	159	764.000	75.0	1580.00	155.00	1:16	2	29.8	142.6

The final appearance shape and characteristics need to be discussed.
Depending on the required quantities, it might be difficult to accept the request.
