M22E-13G

Click the arrow icon in the table below to switch from ascending to descending order.

scroll

Model	Rated Voltage [V]	No load speed [min-1]	No Load Current [mA]	Rated Load [gf･cm]	Rated Load [mN・m]	Rated Load Speed [min-1]	Rated Load Current [mA]	Max Rated Load Torque [gf･cm]	Max Rated Load Torque [mN・m]	Starting Torque [gf･cm]	Starting Torque [mN・m]	Gear Ratio	Gear Step	Gear Box L1 [mm]	Weight [g]
M22E-13G(1:35)	6.0	160	100.0	1000.00	98.00	135	480	2550.000	250.0	5918.00	580.00	1:35	4	21.5	56.0
M22E-13G(1:50)	6.0	119	100.0	1000.00	98.00	104	370	2550.000	250.0	8265.00	810.00	1:50	4	21.5	56.0
M22E-13G(1:75)	6.0	77	100.0	1500.00	147.00	68	420	4080.000	400.0	12448.00	1220.00	1:75	5	21.5	56.0
M22E-13G(1:100)	6.0	58	100.0	1500.00	147.00	53	340	5100.000	500.0	16530.00	1620.00	1:100	5	21.5	56.0
M22E-13G(1:125)	6.0	47	100.0	2000.00	196.00	42	360	5100.000	500.0	20408.00	2000.00	1:125	5	21.5	56.0
M22E-13G(1:150)	6.0	39	100.0	2000.00	196.00	36	310	5100.000	500.0	25510.00	2500.00	1:150	5	21.5	56.0
