SE10J

Click the arrow icon in the table below to switch from ascending to descending order.

scroll

Model	Operating Voltage lower limit [V]	Operating Voltage upper limit [V]	Rated Voltage [V]	No load speed [min-1]	No Load Current [mA]	Rated Load [gf･cm]	Rated Load [mN・m]	Rated Load Speed [min-1]	Rated Load Current [mA]	Starting Torque [gf･cm]	Starting Torque [mN・m]	Starting current [mA]
SE10J0VTM	1.0	5.5	5.0	9171	63.0	8.20	0.80	7000	229	34.50	3.40	766
SE10J0RTM	1.0	5.5	5.0	5506	23.0	5.10	0.50	4163	85	20.90	2.00	278
SE10J1BTM	1.0	5.5	3.0	7160	69.0	6.10	0.60	5437	250	25.40	2.50	823
