The most typical type of radial ball bearings can support axial loads in both directions in addition to radial loads. Some types have a flange or retaining ring on the outer ring to facilitate axial positioning when mounting the housing.
-
-
NMB Parts No. DDL-2112DD Metric or Inch Metric ISO/JIS 6801DD Material of Rings Stainless Steel Ring Type [Radial] basic type Inner Diameter(d)
[mm]12.000 Inner Diameter(d)Tolerance
[mm]Compliant with JIS standards Outer Diameter(D)
[mm]21.000 Outer Diameter(D)Tolerance
[mm]Compliant with JIS standards Width(B)
[mm]5.000 Width(B)Tolerance
[mm]Compliant with JIS standards Chamfer(rs min)
[mm]0.300 Reference Diameter Outer(Lo)
[mm]19.220 Reference Diameter Inner(Li)
[mm]14.400 Ball Size(DW)
[mm]2.3813 Ball Complement(Z) 12 Dynamic Load Rating(Cr)
[N]1917 Static Load Rating(Cor)
[N]1042 Inner Diameter(d)
[in]0.4724 Outer Diameter(D)
[in]0.8268
-
