K23KM(K Series)

This is the "M Series", which is equipped with a battery-less absolute encoder that achieves a slim design with our unique sensor mechanism on a hybrid type stepping motor.

By applying the time measurement mechanism of an analog clock, our absolute encoder can maintain the current position even when not powered, without the need for a backup power source. Furthermore, it is possible to resume operation without returning to the origin even after restart, contributing to the reduction of tact time while reducing the need for origin sensors and limit sensors required for returning to the origin.

The position detection method can be chosen from absolute output and incremental output, and the size is available in 9 types with different L dimensions of □28mm / □42mm / □56.4mm.

Click the arrow icon in the table below to switch from ascending to descending order.

scroll

Model	Outer Diameter [mm]	Full length [mm]	Step Angle [°]	Drive Sequence	Rated Current [A]	Resistance [Ω]	Holding Torque [mN・m]	Inductance [mH]	Rotor Inertia [g・cm2]	Detent Torque [mN・m]	Encoder Resolution [CPR]	Maximum turn count	Mass [g]
K23KM-K044B	56.4	64.0	1.800	BI-POLAR	2.20	1.70	1000	7.20	200.00	34.00	4000	1	690
K23KM-K144B	56.4	76.0	1.800	BI-POLAR	2.10	2.00	1250	8.70	290.00	49.00	4000	1	910
K23KM-K249B	56.4	52.0	1.800	BI-POLAR	1.40	2.40	540	7.70	120.00	20.00	4000	1	480
K23KM-K349B	56.4	60.0	1.800	BI-POLAR	1.40	3.00	800	11.80	180.00	29.00	4000	1	600
K23KM-K744B	56.4	86.0	1.800	BI-POLAR	2.00	2.30	1500	10.60	360.00	50.00	4000	1	1060
K23KM-H056B	56.4	64.0	1.800	BI-POLAR	2.00	1.70	1330	7.30	320.00	54.00	4000	1	690
K23KM-H049B	56.4	64.0	1.800	BI-POLAR	3.00	0.90	1330	3.70	320.00	54.00	4000	1	690
K23KM-H256B	56.4	52.0	1.800	BI-POLAR	2.00	1.30	750	3.80	180.00	47.00	4000	1	480
K23KM-H248B	56.4	52.0	1.800	BI-POLAR	3.00	0.60	750	1.70	180.00	47.00	4000	1	480
K23KM-H355B	56.4	60.0	1.800	BI-POLAR	2.00	1.50	1020	5.40	275.00	49.00	4000	1	600
K23KM-H348B	56.4	60.0	1.800	BI-POLAR	3.00	0.70	1020	2.60	275.00	49.00	4000	1	600
K23KM-H755B	56.4	86.0	1.800	BI-POLAR	2.00	2.30	2200	10.50	550.00	93.00	4000	1	1060
K23KM-H748B	56.4	86.0	1.800	BI-POLAR	3.00	1.20	2200	4.90	550.00	93.00	4000	1	1060
