N17PM(N Series)

Our hybrid stepping motor with encoders are two-phase stepping motors that use MinebeaMitsumi's high-performance ball bearings and come equipped with sensors that detect the positions of the rotors (optical rotary encoder). These motors can obtain information such as rotating speed, rotational direction, angle of rotation and amount of rotation as an output pulse.
Encoder specification: Optical encoder, 3-channel, 1600, 2400 and 4000CPR, Output Type Line driver.

Click the arrow icon in the table below to switch from ascending to descending order.

scroll

Model	Outer Diameter [mm]	Full length [mm]	Step Angle [°]	Drive Sequence	Rated Current [A]	Resistance [Ω]	Holding Torque [mN・m]	Inductance [mH]	Rotor Inertia [g・cm2]	Detent Torque [mN・m]	Encoder Resolution [CPR]	Mass [g]
N17PM-K053B	42.0	44.0	1.800	BI-POLAR	1.20	2.20	270	4.60	37.00	11.00	4000	210
N17PM-K058B	42.0	44.0	1.800	BI-POLAR	1.00	3.00	270	6.40	37.00	11.00	4000	210
N17PM-K046B	42.0	44.0	1.800	BI-POLAR	0.80	5.00	270	10.30	37.00	11.00	4000	210
N17PM-K049B	42.0	44.0	1.800	BI-POLAR	0.70	6.40	270	12.80	37.00	11.00	4000	210
N17PM-K051B	42.0	44.0	1.800	BI-POLAR	0.65	7.80	270	15.90	37.00	11.00	4000	210
N17PM-K149B	42.0	52.0	1.800	BI-POLAR	1.40	2.20	380	6.10	62.00	11.80	4000	310
N17PM-K142B	42.0	52.0	1.800	BI-POLAR	1.00	4.60	380	12.90	62.00	11.80	4000	310
N17PM-K249B	42.0	40.0	1.800	BI-POLAR	0.60	5.40	140	12.00	24.00	4.30	4000	190
N17PM-K348B	42.0	48.0	1.800	BI-POLAR	1.40	1.80	310	4.30	50.00	11.30	4000	260
N17PM-K353B	42.0	48.0	1.800	BI-POLAR	1.20	2.50	310	6.20	50.00	11.30	4000	260
N17PM-K342B	42.0	48.0	1.800	BI-POLAR	0.90	4.00	310	9.90	50.00	11.30	4000	260
N17PM-K349B	42.0	48.0	1.800	BI-POLAR	0.70	7.40	310	18.00	50.00	11.30	4000	260
N17PM-K448B	42.0	58.0	1.800	BI-POLAR	1.50	2.40	500	5.80	75.00	16.70	4000	360
N17PM-K442B	42.0	58.0	1.800	BI-POLAR	0.90	5.60	500	13.60	75.00	16.70	4000	360
N17PM-K749B	42.0	36.0	1.800	BI-POLAR	0.60	4.40	65	6.40	11.00	2.80	4000	160
N17PM-KA45B	42.0	70.0	1.800	BI-POLAR	1.50	2.70	610	7.50	120.00	21.60	4000	500
N17PM-KA39B	42.0	70.0	1.800	BI-POLAR	1.00	6.00	610	15.90	120.00	21.60	4000	500
