N10PM(N Series)

Our hybrid stepping motor with encoders are two-phase stepping motors that use MinebeaMitsumi's high-performance ball bearings and come equipped with sensors that detect the positions of the rotors (optical rotary encoder). These motors can obtain information such as rotating speed, rotational direction, angle of rotation and amount of rotation as an output pulse.
Encoder specification: Optical encoder, 3-channel, 1600, 2400 and 4000CPR, Output Type Line driver.

Click the arrow icon in the table below to switch from ascending to descending order.

scroll

Model	Outer Diameter [mm]	Full length [mm]	Step Angle [°]	Drive Sequence	Rated Current [A]	Resistance [Ω]	Holding Torque [mN・m]	Inductance [mH]	Rotor Inertia [g・cm2]	Detent Torque [mN・m]	Encoder Resolution [CPR]	Mass [g]
N10PM-K013B	25.0	37.5	1.800	BI-POLAR	0.21	47.00	49	30.00	3.00	2.50	4000	80
N10PM-K006B	25.0	37.5	1.800	BI-POLAR	0.80	2.60	49	1.70	3.00	2.50	4000	80
N10PM-K105B	25.0	50.5	1.800	BI-POLAR	1.50	1.20	90	1.00	8.00	4.00	4000	120
N10PM-K106B	25.0	50.5	1.800	BI-POLAR	1.00	3.00	90	2.50	8.00	4.00	4000	120
N10PM-K202B	25.0	33.5	1.800	BI-POLAR	0.70	3.80	33	2.00	2.00	2.00	4000	65
N10PM-K267B	25.0	33.5	1.800	BI-POLAR	0.50	7.70	33	3.50	2.00	2.00	4000	65
N10PM-K405B	25.0	61.5	1.800	BI-POLAR	1.50	1.60	120	1.60	12.00	5.00	4000	160
N10PM-K406B	25.0	61.5	1.800	BI-POLAR	1.00	3.80	120	3.60	12.00	5.00	4000	160
N10PM-K701B	25.0	43.0	1.800	BI-POLAR	0.63	5.80	62	5.40	5.00	3.00	4000	100
N10PM-K712B	25.0	43.0	1.800	BI-POLAR	0.90	3.10	62	2.80	5.00	3.00	4000	100
