A stick-able film antenna that stably receives terrestrial digital broadcasting.
Features
- Small Size: Antenna Film: 126.5（W）×100（Ｄ）mm Type L
Amplifier: 9.0（W）×36.6（Ｄ）×5.8（Ｈ）mm - Mounting: Easy operation with no earthing sheet required.
- Cable Length: 5m (standard) *Shape of connector can be customized.
- Power Supply Voltage: 8V
Specifications
| Antenna Reception Frequency | 470~770MHz |
|---|---|
| Antenna Reception Polarization | Vertical polarization |
| Antenna Output Impedance | 50Ω |
| LNA Reception Frequency | 470~770MHz |
| LNA Noise Figure | 2.0dB typ. |
| Overall Gain | -3~+8dBi |
| Overall Power Supply Voltage | 8V |
| Overall Current Consumption | 30mA typ. |
| Cable | 1.0D(50Ω) |
| Connector | HF201S |
| Minimum Order | 120,000pcs/year |
Overall View
Unit:mm
NOTE
*Any products mentioned in this catalog are subject to any modification in their appearance and others for improvements without prior notification.
*The details listed here are not a guarantee of the individual products at the time of ordering. When using the products, you will be asked to check their specifications.
