This pump has a MinebeaMitsumi original assembly structure that permits simplification of a pump structure.
Micro air pump of low cost structure with simplified mechanism.
Features
1. Simplified pump structure.
2. Low cost pump by reducing the number of parts and the number of assembly man-hours.
3. The product is patented by MinebeaMitsumi.
4. Assembly method unique to MinebeaMitsumi. A snap fit used to settle the pump unit.
Application case : Blood Pressure Monitor for Home Appliance
-
-
scroll
Item
Specifications
Condition
Rated Voltage
[DC V]3 Used Voltage Range
[DC V]2.0 ～ 3.2 Pressing Time
[sec max.]10 Time to add pressure from 0 to 300mmHg to a tank of 100cc by rated voltage (DC 3V). Current Consumption
[mA max.]450 Maximum current consumption during adding pressure from 0 to 300mHg to a tank of 500cc by rated voltage (DC 3V). Leakage of Air
[mmHg/60sec max.]3 Decrease of pressure at 30 second after stop pumping to a tank of 100cc up to 40±10mmHg and 300 ± 10mmHg. Maximum Pressure
[mmHg min.]350 Noise
[dB max.]55 Noise at 30cm from the pump. -
