Bearings
Miniature & small ball bearings
Deep groove ball bearings
NMB Parts No. | ISO/JIS | Inner Diameter (d) [mm] |
Outer Diameter (D) [mm] |
Width (B) [mm] |
Dynamic Load Rating (Cr) [N] |
Static Load Rating (Cor) [N] |
Inner Diameter (d) [in] |
Outer Diameter (D) [in] |
CAD Data |
---|---|---|---|---|---|---|---|---|---|
DDRI-1634ZZ | - | 19.050 | 25.400 | 3.967 | 1203 | 894 | 0.7500 | 1.0000 | DDRI-1634ZZ |
DDRI-1634 | - | 19.050 | 25.400 | 3.967 | 1203 | 894 | 0.7500 | 1.0000 | DDRI-1634 |
DDRI-1458ZZ | - | 15.875 | 22.225 | 3.967 | 1093 | 742 | 0.6250 | 0.8750 | DDRI-1458ZZ |
RI-1812KK | - | 12.700 | 28.575 | 7.938 | 5113 | 2387 | 0.5000 | 1.1250 | RI-1812KK |
DDRI-1812ZZ | - | 12.700 | 28.575 | 7.938 | 4033 | 2003 | 0.5000 | 1.1250 | DDRI-1812ZZ |
DDRI-1812 | - | 12.700 | 28.575 | 6.350 | 4033 | 2003 | 0.5000 | 1.1250 | DDRI-1812 |
DDRI-1212ZZ | - | 12.700 | 19.050 | 3.967 | 1051 | 662 | 0.5000 | 0.7500 | DDRI-1212ZZ |
RI-1438SS | - | 9.525 | 22.225 | 7.142 | 3297 | 1368 | 0.3750 | 0.8750 | RI-1438SS |
RI-1438DD | - | 9.525 | 22.225 | 7.142 | 3297 | 1368 | 0.3750 | 0.8750 | RI-1438DD |
RI-1438KK | - | 9.525 | 22.225 | 7.142 | 3297 | 1368 | 0.3750 | 0.8750 | RI-1438KK |
RI-1438 | - | 9.525 | 22.225 | 5.558 | 3297 | 1368 | 0.3750 | 0.8750 | RI-1438 |
DDRI-1438ZZ | - | 9.525 | 22.225 | 7.142 | 3334 | 1413 | 0.3750 | 0.8750 | DDRI-1438ZZ |
DDRI-1438 | - | 9.525 | 22.225 | 5.558 | 3334 | 1413 | 0.3750 | 0.8750 | DDRI-1438 |
DDRI-1038ZZ | - | 9.525 | 15.875 | 3.967 | 906 | 477 | 0.3750 | 0.6250 | DDRI-1038ZZ |
DDRI-1038 | - | 9.525 | 15.875 | 3.967 | 906 | 477 | 0.3750 | 0.6250 | DDRI-1038 |
DDRI-8516ZZ | - | 7.938 | 12.700 | 3.967 | 878 | 419 | 0.3125 | 0.5000 | DDRI-8516ZZ |
DDRI-8516 | - | 7.938 | 12.700 | 3.967 | 878 | 419 | 0.3125 | 0.5000 | DDRI-8516 |
RI-1214ZZ | - | 6.350 | 19.050 | 7.142 | 2411 | 912 | 0.2500 | 0.7500 | RI-1214ZZ |
DDRI-1214ZZ | - | 6.350 | 19.050 | 7.142 | 2411 | 912 | 0.2500 | 0.7500 | DDRI-1214ZZ |
DDRI-1214 | - | 6.350 | 19.050 | 5.558 | 2411 | 912 | 0.2500 | 0.7500 | DDRI-1214 |
R-4SS | - | 6.350 | 15.875 | 4.978 | 1470 | 599 | 0.2500 | 0.6250 | R-4SS |
R-4DD | - | 6.350 | 15.875 | 4.978 | 1470 | 599 | 0.2500 | 0.6250 | R-4DD |
R-4KK | - | 6.350 | 15.875 | 4.978 | 1470 | 599 | 0.2500 | 0.6250 | R-4KK |
DDR-4SS | - | 6.350 | 15.875 | 4.978 | 1470 | 599 | 0.2500 | 0.6250 | DDR-4SS |
DDR-4HH | - | 6.350 | 15.875 | 4.978 | 1470 | 599 | 0.2500 | 0.6250 | DDR-4HH |
DDR-4 | - | 6.350 | 15.875 | 4.978 | 1470 | 599 | 0.2500 | 0.6250 | DDR-4 |
RI-814ZZ | - | 6.350 | 12.700 | 4.762 | 828 | 374 | 0.2500 | 0.5000 | RI-814ZZ |
DDRI-814ZZ | - | 6.350 | 12.700 | 4.762 | 828 | 374 | 0.2500 | 0.5000 | DDRI-814ZZ |
DDRI-814 | - | 6.350 | 12.700 | 3.175 | 828 | 374 | 0.2500 | 0.5000 | DDRI-814 |
DDRI-614ZZ | - | 6.350 | 9.525 | 3.175 | 417 | 205 | 0.2500 | 0.3750 | DDRI-614ZZ |
DDRI-614 | - | 6.350 | 9.525 | 3.175 | 417 | 205 | 0.2500 | 0.3750 | DDRI-614 |
R-3DD | - | 4.762 | 12.700 | 4.978 | 1306 | 487 | 0.1875 | 0.5000 | R-3DD |
R-3HH | - | 4.762 | 12.700 | 4.978 | 1306 | 487 | 0.1875 | 0.5000 | R-3HH |
DDR-3ZZ | - | 4.762 | 12.700 | 4.978 | 1306 | 487 | 0.1875 | 0.5000 | DDR-3ZZ |
DDR-3 | - | 4.762 | 12.700 | 3.967 | 1306 | 487 | 0.1875 | 0.5000 | DDR-3 |
RI-6632ZZ | - | 4.762 | 9.525 | 3.175 | 712 | 271 | 0.1875 | 0.3750 | RI-6632ZZ |
DDRI-6632ZZ | - | 4.762 | 9.525 | 3.175 | 712 | 271 | 0.1875 | 0.3750 | DDRI-6632ZZ |
DDRI-6632 | - | 4.762 | 9.525 | 3.175 | 712 | 271 | 0.1875 | 0.3750 | DDRI-6632 |
DDRI-5632ZZ | - | 4.762 | 7.938 | 3.175 | 391 | 142 | 0.1875 | 0.3125 | DDRI-5632ZZ |
DDRI-5632 | - | 4.762 | 7.938 | 2.779 | 391 | 142 | 0.1875 | 0.3125 | DDRI-5632 |
DDRI-5532ZZ | - | 3.967 | 7.938 | 3.175 | 391 | 142 | 0.1562 | 0.3125 | DDRI-5532ZZ |
DDRI-5532 | - | 3.967 | 7.938 | 2.779 | 391 | 142 | 0.1562 | 0.3125 | DDRI-5532 |
DDRI-618ZZ | - | 3.175 | 9.525 | 3.571 | 563 | 183 | 0.1250 | 0.3750 | DDRI-618ZZ |
DDRI-618 | - | 3.175 | 9.525 | 2.779 | 563 | 183 | 0.1250 | 0.3750 | DDRI-618 |
R-2DD | - | 3.175 | 9.525 | 3.967 | 641 | 226 | 0.1250 | 0.3750 | R-2DD |
R-2KK1 | - | 3.175 | 9.525 | 3.967 | 641 | 226 | 0.1250 | 0.3750 | R-2KK1 |
DDR-2ZZ | - | 3.175 | 9.525 | 3.967 | 641 | 226 | 0.1250 | 0.3750 | DDR-2ZZ |
DDR-2 | - | 3.175 | 9.525 | 3.967 | 641 | 226 | 0.1250 | 0.3750 | DDR-2 |
DDRI-518ZZ | - | 3.175 | 7.938 | 3.571 | 563 | 183 | 0.1250 | 0.3125 | DDRI-518ZZ |
DDRI-518 | - | 3.175 | 7.938 | 2.779 | 563 | 183 | 0.1250 | 0.3125 | DDRI-518 |
DDRI-418ZZ | - | 3.175 | 6.350 | 2.779 | 285 | 97 | 0.1250 | 0.2500 | DDRI-418ZZ |
DDRI-418 | - | 3.175 | 6.350 | 2.380 | 285 | 97 | 0.1250 | 0.2500 | DDRI-418 |
DDRI-5ZZ | - | 2.380 | 7.938 | 3.571 | 563 | 183 | 0.0937 | 0.3125 | DDRI-5ZZ |
DDRI-5 | - | 2.380 | 7.938 | 2.779 | 563 | 183 | 0.0937 | 0.3125 | DDRI-5 |
DDRI-3332ZZ | - | 2.380 | 4.762 | 2.380 | 187 | 59 | 0.0937 | 0.1875 | DDRI-3332ZZ |
DDRI-3332 | - | 2.380 | 4.762 | 1.588 | 187 | 59 | 0.0937 | 0.1875 | DDRI-3332 |
DDRI-4ZZ | - | 1.984 | 6.350 | 3.571 | 330 | 99 | 0.0781 | 0.2500 | DDRI-4ZZ |
DDRI-4 | - | 1.984 | 6.350 | 2.380 | 330 | 99 | 0.0781 | 0.2500 | DDRI-4 |
DDRI-3ZZ | - | 1.397 | 4.762 | 2.779 | 264 | 71 | 0.0550 | 0.1875 | DDRI-3ZZ |
DDRI-3 | - | 1.397 | 4.762 | 1.984 | 264 | 71 | 0.0550 | 0.1875 | DDRI-3 |
DDRI-2X2 | - | 1.016 | 3.175 | 1.191 | 106 | 28 | 0.0400 | 0.1250 | DDRI-2X2 |
DDA-2520ZZ | - | 20.000 | 25.000 | 4.000 | 1012 | 691 | 0.7874 | 0.9843 | DDA-2520ZZ |
DDA-2520 | - | 20.000 | 25.000 | 4.000 | 1012 | 691 | 0.7874 | 0.9843 | DDA-2520 |
DDA-2418 | - | 18.000 | 24.000 | 4.000 | 988 | 654 | 0.7087 | 0.9449 | DDA-2418 |
DDA-2216SS | - | 16.000 | 22.000 | 4.000 | 969 | 619 | 0.6299 | 0.8661 | DDA-2216SS |
DDA-2216ZZ | - | 16.000 | 22.000 | 4.000 | 969 | 619 | 0.6299 | 0.8661 | DDA-2216ZZ |
DDA-2216 | - | 16.000 | 22.000 | 4.000 | 969 | 619 | 0.6299 | 0.8661 | DDA-2216 |
DDA-2115DD | - | 15.000 | 21.000 | 4.000 | 938 | 581 | 0.5906 | 0.7874 | DDA-2115DD |
DDA-2115 | - | 15.000 | 21.000 | 3.500 | 938 | 581 | 0.5906 | 0.7874 | DDA-2115 |
DDA-2015ZZ | - | 15.000 | 20.000 | 4.500 | 944 | 582 | 0.5906 | 0.7874 | DDA-2015ZZ |
DDA-2015 | - | 15.000 | 20.000 | 3.500 | 944 | 582 | 0.5906 | 0.7874 | DDA-2015 |
DDR-2412X3DD | 6901DD | 12.000 | 24.000 | 6.000 | 3082 | 1433 | 0.4724 | 0.9449 | DDR-2412X3DD |
DDR-2412X3ZZ | 6901ZZ | 12.000 | 24.000 | 6.000 | 3082 | 1433 | 0.4724 | 0.9449 | DDR-2412X3ZZ |
DDL-2112SS | 6801SS | 12.000 | 21.000 | 5.000 | 1917 | 1042 | 0.4724 | 0.8268 | DDL-2112SS |
DDL-2112DD | 6801DD | 12.000 | 21.000 | 5.000 | 1917 | 1042 | 0.4724 | 0.8268 | DDL-2112DD |
DDL-2112 | 6801 | 12.000 | 21.000 | 5.000 | 1917 | 1042 | 0.4724 | 0.8268 | DDL-2112 |
DDR-2210X2HH | 6900ZZ | 10.000 | 22.000 | 6.000 | 2697 | 1273 | 0.3937 | 0.8661 | DDR-2210X2HH |
DDR-2210X2 | 6900 | 10.000 | 22.000 | 6.000 | 2697 | 1273 | 0.3937 | 0.8661 | DDR-2210X2 |
DDL-1910DD | - | 10.000 | 19.000 | 7.000 | 2123 | 985 | 0.3937 | 0.7480 | DDL-1910DD |
DDL-1910DDY05 | 6800DD | 10.000 | 19.000 | 5.000 | 2123 | 985 | 0.3937 | 0.7480 | DDL-1910DDY05 |
DDL-1910ZZY05 | 6800ZZ | 10.000 | 19.000 | 5.000 | 2123 | 985 | 0.3937 | 0.7480 | DDL-1910ZZY05 |
DDL-1910ZZ | - | 10.000 | 19.000 | 7.000 | 2123 | 985 | 0.3937 | 0.7480 | DDL-1910ZZ |
DDL-1910 | 6800 | 10.000 | 19.000 | 5.000 | 2123 | 985 | 0.3937 | 0.7480 | DDL-1910 |
DDA-1510ZZ | - | 10.000 | 15.000 | 4.000 | 857 | 435 | 0.3937 | 0.5906 | DDA-1510ZZ |
DDA-1510 | 6700 | 10.000 | 15.000 | 3.000 | 857 | 435 | 0.3937 | 0.5906 | DDA-1510 |
DDL-2090ZZ | 699ZZ | 9.000 | 20.000 | 6.000 | 2123 | 985 | 0.3543 | 0.7874 | DDL-2090ZZ |
DDL-2090 | 699 | 9.000 | 20.000 | 6.000 | 2123 | 985 | 0.3543 | 0.7874 | DDL-2090 |
DDL-1790DD | - | 9.000 | 17.000 | 5.000 | 1724 | 813 | 0.3543 | 0.6693 | DDL-1790DD |
DDL-1790ZZ | - | 9.000 | 17.000 | 5.000 | 1724 | 813 | 0.3543 | 0.6693 | DDL-1790ZZ |
DDL-1790 | 689 | 9.000 | 17.000 | 4.000 | 1724 | 813 | 0.3543 | 0.6693 | DDL-1790 |
DDR-2280DD | 608DD | 8.000 | 22.000 | 7.000 | 3297 | 1368 | 0.3150 | 0.8661 | DDR-2280DD |
DDR-2280HH | 608ZZ | 8.000 | 22.000 | 7.000 | 3297 | 1368 | 0.3150 | 0.8661 | DDR-2280HH |
DDR-2280 | 608 | 8.000 | 22.000 | 7.000 | 3297 | 1368 | 0.3150 | 0.8661 | DDR-2280 |
DDR-1980DD | 698DD | 8.000 | 19.000 | 6.000 | 2463 | 1059 | 0.3150 | 0.7480 | DDR-1980DD |
DDR-1980ZZ | 698ZZ | 8.000 | 19.000 | 6.000 | 2240 | 912 | 0.3150 | 0.7480 | DDR-1980ZZ |
DDR-1980 | 698 | 8.000 | 19.000 | 6.000 | 2240 | 912 | 0.3150 | 0.7480 | DDR-1980 |
DDL-1680DD | - | 8.000 | 16.000 | 5.000 | 1606 | 712 | 0.3150 | 0.6299 | DDL-1680DD |
DDL-1680HH | - | 8.000 | 16.000 | 5.000 | 1606 | 712 | 0.3150 | 0.6299 | DDL-1680HH |
DDL-1680 | 688 | 8.000 | 16.000 | 4.000 | 1606 | 712 | 0.3150 | 0.6299 | DDL-1680 |
DDL-1480ZZ | - | 8.000 | 14.000 | 4.000 | 819 | 386 | 0.3150 | 0.5512 | DDL-1480ZZ |
DDL-1480 | - | 8.000 | 14.000 | 3.500 | 819 | 386 | 0.3150 | 0.5512 | DDL-1480 |
DDL-1280ZZ | - | 8.000 | 12.000 | 3.500 | 506 | 249 | 0.3150 | 0.4724 | DDL-1280ZZ |
DDL-1280 | 678 | 8.000 | 12.000 | 2.500 | 506 | 249 | 0.3150 | 0.4724 | DDL-1280 |
DDR-2270HH | 627ZZ | 7.000 | 22.000 | 7.000 | 3297 | 1368 | 0.2756 | 0.8661 | DDR-2270HH |
DDR-2270 | 627 | 7.000 | 22.000 | 7.000 | 3297 | 1368 | 0.2756 | 0.8661 | DDR-2270 |
DDR-1970ZZ | 607ZZ | 7.000 | 19.000 | 6.000 | 2240 | 912 | 0.2756 | 0.7480 | DDR-1970ZZ |
DDR-1970 | 607 | 7.000 | 19.000 | 6.000 | 2240 | 912 | 0.2756 | 0.7480 | DDR-1970 |
DDL-1470ZZ | - | 7.000 | 14.000 | 5.000 | 1175 | 511 | 0.2756 | 0.5512 | DDL-1470ZZ |
DDL-1470 | 687 | 7.000 | 14.000 | 3.500 | 1175 | 511 | 0.2756 | 0.5512 | DDL-1470 |
DDL-1370ZZ | - | 7.000 | 13.000 | 4.000 | 880 | 414 | 0.2756 | 0.5118 | DDL-1370ZZ |
DDL-1370 | - | 7.000 | 13.000 | 3.000 | 880 | 414 | 0.2756 | 0.5118 | DDL-1370 |
DDL-1170DD | - | 7.000 | 11.000 | 3.000 | 449 | 199 | 0.2756 | 0.4331 | DDL-1170DD |
DDL-1170ZZ | - | 7.000 | 11.000 | 3.000 | 449 | 199 | 0.2756 | 0.4331 | DDL-1170ZZ |
DDL-1170 | 677 | 7.000 | 11.000 | 2.500 | 449 | 199 | 0.2756 | 0.4331 | DDL-1170 |
DDR-1960DD | 626DD | 6.000 | 19.000 | 6.000 | 2805 | 1060 | 0.2362 | 0.7480 | DDR-1960DD |
DDR-1960ZZ | 626ZZ | 6.000 | 19.000 | 6.000 | 2805 | 1060 | 0.2362 | 0.7480 | DDR-1960ZZ |
DDR-1960 | 626 | 6.000 | 19.000 | 6.000 | 2805 | 1060 | 0.2362 | 0.7480 | DDR-1960 |
DDR-1760X2DD | 606DD | 6.000 | 17.000 | 6.000 | 2265 | 839 | 0.2362 | 0.6693 | DDR-1760X2DD |
DDR-1760X2ZZ | 606ZZ | 6.000 | 17.000 | 6.000 | 2265 | 839 | 0.2362 | 0.6693 | DDR-1760X2ZZ |
DDR-1760X2 | 606 | 6.000 | 17.000 | 6.000 | 2265 | 839 | 0.2362 | 0.6693 | DDR-1760X2 |
DDR-1660HH | - | 6.000 | 16.000 | 5.000 | 1735 | 671 | 0.2362 | 0.6299 | DDR-1660HH |
DDR-1560DD | 696DD | 6.000 | 15.000 | 5.000 | 1735 | 671 | 0.2362 | 0.5906 | DDR-1560DD |
DDR-1560ZZ | 696ZZ | 6.000 | 15.000 | 5.000 | 1735 | 671 | 0.2362 | 0.5906 | DDR-1560ZZ |
DDR-1560 | 696 | 6.000 | 15.000 | 5.000 | 1735 | 671 | 0.2362 | 0.5906 | DDR-1560 |
DDL-1360DD | - | 6.000 | 13.000 | 5.000 | 1083 | 438 | 0.2362 | 0.5118 | DDL-1360DD |
DDL-1360ZZ | - | 6.000 | 13.000 | 5.000 | 1083 | 438 | 0.2362 | 0.5118 | DDL-1360ZZ |
DDL-1360 | 686 | 6.000 | 13.000 | 3.500 | 1083 | 438 | 0.2362 | 0.5118 | DDL-1360 |
DDL-1260X2DD | - | 6.000 | 12.000 | 4.000 | 831 | 363 | 0.2362 | 0.4724 | DDL-1260X2DD |
DDL-1260ZZ | - | 6.000 | 12.000 | 4.000 | 831 | 363 | 0.2362 | 0.4724 | DDL-1260ZZ |
DDL-1260 | - | 6.000 | 12.000 | 3.000 | 831 | 363 | 0.2362 | 0.4724 | DDL-1260 |
DDL-1060DD | - | 6.000 | 10.000 | 3.000 | 457 | 194 | 0.2362 | 0.3937 | DDL-1060DD |
DDL-1060ZZ | - | 6.000 | 10.000 | 3.000 | 457 | 194 | 0.2362 | 0.3937 | DDL-1060ZZ |
DDL-1060 | 676 | 6.000 | 10.000 | 2.500 | 457 | 194 | 0.2362 | 0.3937 | DDL-1060 |
DDR-1950ZZ | 635ZZ | 5.000 | 19.000 | 6.000 | 2805 | 1060 | 0.1969 | 0.7480 | DDR-1950ZZ |
DDR-1950 | 635 | 5.000 | 19.000 | 6.000 | 2805 | 1060 | 0.1969 | 0.7480 | DDR-1950 |
DDR-1650DD | 625DD | 5.000 | 16.000 | 5.000 | 1735 | 671 | 0.1969 | 0.6299 | DDR-1650DD |
DDR-1650HH | 625ZZ | 5.000 | 16.000 | 5.000 | 1735 | 671 | 0.1969 | 0.6299 | DDR-1650HH |
DDR-1650 | 625 | 5.000 | 16.000 | 5.000 | 1735 | 671 | 0.1969 | 0.6299 | DDR-1650 |
DDR-1450ZZ | 605ZZ | 5.000 | 14.000 | 5.000 | 1329 | 508 | 0.1969 | 0.5512 | DDR-1450ZZ |
DDR-1450 | 605 | 5.000 | 14.000 | 5.000 | 1329 | 508 | 0.1969 | 0.5512 | DDR-1450 |
DDR-1350ZZ | 695ZZ | 5.000 | 13.000 | 4.000 | 1074 | 422 | 0.1969 | 0.5118 | DDR-1350ZZ |
DDR-1350 | 695 | 5.000 | 13.000 | 4.000 | 1306 | 487 | 0.1969 | 0.5118 | DDR-1350 |
DDL-1150ZZY04 | - | 5.000 | 11.000 | 4.000 | 714 | 276 | 0.1969 | 0.4331 | DDL-1150ZZY04 |
DDL-1150W04 | - | 5.000 | 11.000 | 4.000 | 714 | 276 | 0.1969 | 0.4331 | DDL-1150W04 |
DDL-1150ZZ | - | 5.000 | 11.000 | 5.000 | 714 | 276 | 0.1969 | 0.4331 | DDL-1150ZZ |
DDL-1150 | 685 | 5.000 | 11.000 | 3.000 | 714 | 276 | 0.1969 | 0.4331 | DDL-1150 |
DDL-1050SS | - | 5.000 | 10.000 | 4.000 | 714 | 276 | 0.1969 | 0.3937 | DDL-1050SS |
DDL-1050ZZ | - | 5.000 | 10.000 | 4.000 | 714 | 276 | 0.1969 | 0.3937 | DDL-1050ZZ |
DDL-1050 | - | 5.000 | 10.000 | 3.000 | 714 | 276 | 0.1969 | 0.3937 | DDL-1050 |
DDL-950ZZ | - | 5.000 | 9.000 | 3.000 | 495 | 207 | 0.1969 | 0.3543 | DDL-950ZZ |
DDL-950 | - | 5.000 | 9.000 | 2.500 | 495 | 207 | 0.1969 | 0.3543 | DDL-950 |
DDL-850ZZ | - | 5.000 | 8.000 | 2.500 | 274 | 130 | 0.1969 | 0.3150 | DDL-850ZZ |
DDL-850 | 675 | 5.000 | 8.000 | 2.000 | 274 | 130 | 0.1969 | 0.3150 | DDL-850 |
DDR-1340DD | 624DD | 4.000 | 13.000 | 5.000 | 1306 | 487 | 0.1575 | 0.5118 | DDR-1340DD |
DDR-1340ZZ | 624ZZ | 4.000 | 13.000 | 5.000 | 1306 | 487 | 0.1575 | 0.5118 | DDR-1340ZZ |
DDR-1340 | 624 | 4.000 | 13.000 | 5.000 | 1306 | 487 | 0.1575 | 0.5118 | DDR-1340 |
DDR-1240ZZ | 604ZZ | 4.000 | 12.000 | 4.000 | 959 | 347 | 0.1575 | 0.4724 | DDR-1240ZZ |
DDR-1240 | 604 | 4.000 | 12.000 | 4.000 | 959 | 347 | 0.1575 | 0.4724 | DDR-1240 |
DDR-1140ZZ | 694ZZ | 4.000 | 11.000 | 4.000 | 714 | 276 | 0.1575 | 0.4331 | DDR-1140ZZ |
DDR-1140 | 694 | 4.000 | 11.000 | 4.000 | 714 | 276 | 0.1575 | 0.4331 | DDR-1140 |
DDL-1040ZZ | - | 4.000 | 10.000 | 4.000 | 708 | 266 | 0.1575 | 0.3937 | DDL-1040ZZ |
DDL-1040 | - | 4.000 | 10.000 | 3.000 | 708 | 266 | 0.1575 | 0.3937 | DDL-1040 |
DDL-940ZZ | - | 4.000 | 9.000 | 4.000 | 641 | 226 | 0.1575 | 0.3543 | DDL-940ZZ |
DDL-940 | 684 | 4.000 | 9.000 | 2.500 | 641 | 226 | 0.1575 | 0.3543 | DDL-940 |
DDL-840ZZ | - | 4.000 | 8.000 | 3.000 | 391 | 140 | 0.1575 | 0.3150 | DDL-840ZZ |
DDL-840 | - | 4.000 | 8.000 | 2.000 | 391 | 140 | 0.1575 | 0.3150 | DDL-840 |
DDL-740ZZ | - | 4.000 | 7.000 | 2.500 | 252 | 106 | 0.1575 | 0.2756 | DDL-740ZZ |
DDL-740 | 674 | 4.000 | 7.000 | 2.000 | 252 | 106 | 0.1575 | 0.2756 | DDL-740 |
DDR-1030ZZ | 623ZZ | 3.000 | 10.000 | 4.000 | 641 | 226 | 0.1181 | 0.3937 | DDR-1030ZZ |
DDR-1030 | 623 | 3.000 | 10.000 | 4.000 | 641 | 226 | 0.1181 | 0.3937 | DDR-1030 |
DDR-930ZZY04 | - | 3.000 | 9.000 | 4.000 | 634 | 219 | 0.1181 | 0.3543 | DDR-930ZZY04 |
DDR-930ZZ | - | 3.000 | 9.000 | 5.000 | 634 | 219 | 0.1181 | 0.3543 | DDR-930ZZ |
DDR-930 | 603 | 3.000 | 9.000 | 3.000 | 634 | 219 | 0.1181 | 0.3543 | DDR-930 |
DDR-830ZZ | - | 3.000 | 8.000 | 4.000 | 553 | 176 | 0.1181 | 0.3150 | DDR-830ZZ |
DDR-830 | 693 | 3.000 | 8.000 | 3.000 | 553 | 176 | 0.1181 | 0.3150 | DDR-830 |
DDL-730ZZ | - | 3.000 | 7.000 | 3.000 | 384 | 129 | 0.1181 | 0.2756 | DDL-730ZZ |
DDL-730 | 683 | 3.000 | 7.000 | 2.000 | 384 | 129 | 0.1181 | 0.2756 | DDL-730 |
DDL-630ZZ | - | 3.000 | 6.000 | 2.500 | 206 | 73 | 0.1181 | 0.2362 | DDL-630ZZ |
DDL-630 | 673 | 3.000 | 6.000 | 2.000 | 206 | 73 | 0.1181 | 0.2362 | DDL-630 |
DDR-825ZZ | - | 2.500 | 8.000 | 4.000 | 553 | 176 | 0.0984 | 0.3150 | DDR-825ZZ |
DDR-825 | 60/2.5 | 2.500 | 8.000 | 2.800 | 553 | 176 | 0.0984 | 0.3150 | DDR-825 |
DDR-725ZZ | - | 2.500 | 7.000 | 3.500 | 380 | 126 | 0.0984 | 0.2756 | DDR-725ZZ |
DDR-725 | 69/2.5 | 2.500 | 7.000 | 2.500 | 380 | 126 | 0.0984 | 0.2756 | DDR-725 |
DDL-625ZZ | - | 2.500 | 6.000 | 2.600 | 206 | 73 | 0.0984 | 0.2362 | DDL-625ZZ |
DDL-625 | 68/2.5 | 2.500 | 6.000 | 1.800 | 206 | 73 | 0.0984 | 0.2362 | DDL-625 |
DDR-720ZZY03 | - | 2.000 | 7.000 | 3.000 | 380 | 126 | 0.0787 | 0.2756 | DDR-720ZZY03 |
DDR-720ZZ | - | 2.000 | 7.000 | 3.500 | 380 | 126 | 0.0787 | 0.2756 | DDR-720ZZ |
DDR-720 | 602 | 2.000 | 7.000 | 2.800 | 380 | 126 | 0.0787 | 0.2756 | DDR-720 |
DDR-620ZZ | - | 2.000 | 6.000 | 3.000 | 330 | 99 | 0.0787 | 0.2362 | DDR-620ZZ |
DDR-620ZZY52 | - | 2.000 | 6.000 | 2.500 | 330 | 99 | 0.0787 | 0.2362 | DDR-620ZZY52 |
DDR-620W52 | - | 2.000 | 6.000 | 2.500 | 330 | 99 | 0.0787 | 0.2362 | DDR-620W52 |
DDR-620ZZY32 | 692ZZ | 2.000 | 6.000 | 2.300 | 279 | 89 | 0.0787 | 0.2362 | DDR-620ZZY32 |
DDR-620 | 692 | 2.000 | 6.000 | 2.300 | 279 | 89 | 0.0787 | 0.2362 | DDR-620 |
DDL-520ZZW52 | - | 2.000 | 5.000 | 2.500 | 187 | 59 | 0.0787 | 0.1969 | DDL-520ZZW52 |
DDL-520W52 | - | 2.000 | 5.000 | 2.500 | 187 | 59 | 0.0787 | 0.1969 | DDL-520W52 |
DDL-520ZZ | - | 2.000 | 5.000 | 2.300 | 187 | 59 | 0.0787 | 0.1969 | DDL-520ZZ |
DDL-520 | 682 | 2.000 | 5.000 | 1.500 | 187 | 59 | 0.0787 | 0.1969 | DDL-520 |
DDL-420 | 672 | 2.000 | 4.000 | 1.200 | 125 | 41 | 0.0787 | 0.1575 | DDL-420 |
DDR-615ZZ | - | 1.500 | 6.000 | 3.000 | 324 | 97 | 0.0591 | 0.2362 | DDR-615ZZ |
DDR-615 | 60/1.5 | 1.500 | 6.000 | 2.500 | 324 | 97 | 0.0591 | 0.2362 | DDR-615 |
DDR-515ZZ | - | 1.500 | 5.000 | 2.600 | 184 | 57 | 0.0591 | 0.1969 | DDR-515ZZ |
DDR-515 | 69/1.5 | 1.500 | 5.000 | 2.000 | 184 | 57 | 0.0591 | 0.1969 | DDR-515 |
DDL-415ZZ | - | 1.500 | 4.000 | 2.000 | 125 | 38 | 0.0591 | 0.1575 | DDL-415ZZ |
DDL-415 | 68/1.5 | 1.500 | 4.000 | 1.200 | 125 | 38 | 0.0591 | 0.1575 | DDL-415 |
DDR-412 | - | 1.200 | 4.000 | 1.800 | 158 | 44 | 0.0472 | 0.1575 | DDR-412 |
DDR-410XZZ | - | 1.000 | 4.000 | 2.000 | 125 | 38 | 0.0394 | 0.1575 | DDR-410XZZ |
DDR-410 | 691 | 1.000 | 4.000 | 1.600 | 158 | 44 | 0.0394 | 0.1575 | DDR-410 |
DDL-310 | 681 | 1.000 | 3.000 | 1.000 | 80 | 23 | 0.0394 | 0.1181 | DDL-310 |
R-2412X3DD | 6901DD | 12.000 | 24.000 | 6.000 | 3082 | 1433 | 0.4724 | 0.9449 | R-2412X3DD |
R-2412X3KK | 6901ZZ | 12.000 | 24.000 | 6.000 | 3082 | 1433 | 0.4724 | 0.9449 | R-2412X3KK |
R-2412X3 | 6901 | 12.000 | 24.000 | 6.000 | 3082 | 1433 | 0.4724 | 0.9449 | R-2412X3 |
L-2112SS | 6801SS | 12.000 | 21.000 | 5.000 | 1917 | 1042 | 0.4724 | 0.8268 | L-2112SS |
L-2112DD | 6801DD | 12.000 | 21.000 | 5.000 | 1917 | 1042 | 0.4724 | 0.8268 | L-2112DD |
L-2112KK | 6801ZZ | 12.000 | 21.000 | 5.000 | 1917 | 1042 | 0.4724 | 0.8268 | L-2112KK |
L-2112 | 6801 | 12.000 | 21.000 | 5.000 | 1917 | 1042 | 0.4724 | 0.8268 | L-2112 |
6000SS | 6000SS | 10.000 | 26.000 | 8.000 | 4578 | 1970 | 0.3937 | 1.0236 | 6000SS |
6000DD | 6000DD | 10.000 | 26.000 | 8.000 | 4578 | 1970 | 0.3937 | 1.0236 | 6000DD |
6000ZZ | 6000ZZ | 10.000 | 26.000 | 8.000 | 4578 | 1970 | 0.3937 | 1.0236 | 6000ZZ |
6000 | 6000 | 10.000 | 26.000 | 8.000 | 4578 | 1970 | 0.3937 | 1.0236 | 6000 |
R-2210X3SS | 6900SS | 10.000 | 22.000 | 6.000 | 2697 | 1273 | 0.3937 | 0.8661 | R-2210X3SS |
R-2210X3DD | 6900DD | 10.000 | 22.000 | 6.000 | 2697 | 1273 | 0.3937 | 0.8661 | R-2210X3DD |
R-2210X3KK | 6900ZZ | 10.000 | 22.000 | 6.000 | 2697 | 1273 | 0.3937 | 0.8661 | R-2210X3KK |
L-1910DDY05 | 6800DD | 10.000 | 19.000 | 5.000 | 2123 | 985 | 0.3937 | 0.7480 | L-1910DDY05 |
L-1910KKY05 | 6800ZZ | 10.000 | 19.000 | 5.000 | 2123 | 985 | 0.3937 | 0.7480 | L-1910KKY05 |
L-1910DD | - | 10.000 | 19.000 | 7.000 | 2123 | 985 | 0.3937 | 0.7480 | L-1910DD |
L-1910 | 6800 | 10.000 | 19.000 | 5.000 | 2123 | 985 | 0.3937 | 0.7480 | L-1910 |
629SSSD61 | 629SS | 9.000 | 26.000 | 8.000 | 4578 | 1970 | 0.3543 | 1.0236 | 629SSSD61 |
629DDSD61 | 629DD | 9.000 | 26.000 | 8.000 | 4578 | 1970 | 0.3543 | 1.0236 | 629DDSD61 |
629ZZSD61 | 629ZZ | 9.000 | 26.000 | 8.000 | 4578 | 1970 | 0.3543 | 1.0236 | 629ZZSD61 |
609SS | 609SS | 9.000 | 24.000 | 7.000 | 3297 | 1368 | 0.3543 | 0.9449 | 609SS |
609DD | 609DD | 9.000 | 24.000 | 7.000 | 3297 | 1368 | 0.3543 | 0.9449 | 609DD |
609ZZ | 609ZZ | 9.000 | 24.000 | 7.000 | 3297 | 1368 | 0.3543 | 0.9449 | 609ZZ |
609 | 609 | 9.000 | 24.000 | 7.000 | 3297 | 1368 | 0.3543 | 0.9449 | 609 |
L-2090KK | 699ZZ | 9.000 | 20.000 | 6.000 | 2123 | 985 | 0.3543 | 0.7874 | L-2090KK |
L-2090 | 699 | 9.000 | 20.000 | 6.000 | 2123 | 985 | 0.3543 | 0.7874 | L-2090 |
L-1790DD | - | 9.000 | 17.000 | 5.000 | 1724 | 813 | 0.3543 | 0.6693 | L-1790DD |
L-1790ZZ | - | 9.000 | 17.000 | 5.000 | 1724 | 813 | 0.3543 | 0.6693 | L-1790ZZ |
L-1790 | 689 | 9.000 | 17.000 | 4.000 | 1724 | 813 | 0.3543 | 0.6693 | L-1790 |
R-2480KK | 628ZZ | 8.000 | 24.000 | 8.000 | 3297 | 1368 | 0.3150 | 0.9449 | R-2480KK |
R-2480 | 628 | 8.000 | 24.000 | 8.000 | 3297 | 1368 | 0.3150 | 0.9449 | R-2480 |
608SS | 608SS | 8.000 | 22.000 | 7.000 | 3297 | 1368 | 0.3150 | 0.8661 | 608SS |
608DD | 608DD | 8.000 | 22.000 | 7.000 | 3297 | 1368 | 0.3150 | 0.8661 | 608DD |
608ZZ | 608ZZ | 8.000 | 22.000 | 7.000 | 3297 | 1368 | 0.3150 | 0.8661 | 608ZZ |
608 | 608 | 8.000 | 22.000 | 7.000 | 3297 | 1368 | 0.3150 | 0.8661 | 608 |
R-1980SS | 698SS | 8.000 | 19.000 | 6.000 | 2463 | 1059 | 0.3150 | 0.7480 | R-1980SS |
R-1980DD | 698DD | 8.000 | 19.000 | 6.000 | 2463 | 1059 | 0.3150 | 0.7480 | R-1980DD |
R-1980KK | 698ZZ | 8.000 | 19.000 | 6.000 | 2463 | 1059 | 0.3150 | 0.7480 | R-1980KK |
R-1980 | 698 | 8.000 | 19.000 | 6.000 | 2463 | 1059 | 0.3150 | 0.7480 | R-1980 |
L-1680DD | - | 8.000 | 16.000 | 5.000 | 1606 | 712 | 0.3150 | 0.6299 | L-1680DD |
L-1680KK | - | 8.000 | 16.000 | 5.000 | 1606 | 712 | 0.3150 | 0.6299 | L-1680KK |
L-1680 | 688 | 8.000 | 16.000 | 4.000 | 1606 | 712 | 0.3150 | 0.6299 | L-1680 |
L-1480DD | - | 8.000 | 14.000 | 4.000 | 819 | 386 | 0.3150 | 0.5512 | L-1480DD |
L-1480ZZ | - | 8.000 | 14.000 | 4.000 | 819 | 386 | 0.3150 | 0.5512 | L-1480ZZ |
L-1280DD | - | 8.000 | 12.000 | 3.500 | 506 | 249 | 0.3150 | 0.4724 | L-1280DD |
L-1280ZZ | - | 8.000 | 12.000 | 3.500 | 506 | 249 | 0.3150 | 0.4724 | L-1280ZZ |
627SS | 627SS | 7.000 | 22.000 | 7.000 | 3297 | 1368 | 0.2756 | 0.8661 | 627SS |
627DD | 627DD | 7.000 | 22.000 | 7.000 | 3297 | 1368 | 0.2756 | 0.8661 | 627DD |
627ZZ | 627ZZ | 7.000 | 22.000 | 7.000 | 3297 | 1368 | 0.2756 | 0.8661 | 627ZZ |
627 | 627 | 7.000 | 22.000 | 7.000 | 3297 | 1368 | 0.2756 | 0.8661 | 627 |
607SS | 607SS | 7.000 | 19.000 | 6.000 | 2614 | 1053 | 0.2756 | 0.7480 | 607SS |
607DD | 607DD | 7.000 | 19.000 | 6.000 | 2614 | 1053 | 0.2756 | 0.7480 | 607DD |
607ZZ | 607ZZ | 7.000 | 19.000 | 6.000 | 2614 | 1053 | 0.2756 | 0.7480 | 607ZZ |
607 | 607 | 7.000 | 19.000 | 6.000 | 2614 | 1053 | 0.2756 | 0.7480 | 607 |
L-1470KK | - | 7.000 | 14.000 | 5.000 | 1175 | 511 | 0.2756 | 0.5512 | L-1470KK |
L-1470 | 687 | 7.000 | 14.000 | 3.500 | 1175 | 511 | 0.2756 | 0.5512 | L-1470 |
L-1370ZZ | - | 7.000 | 13.000 | 4.000 | 880 | 414 | 0.2756 | 0.5118 | L-1370ZZ |
626SS | 626SS | 6.000 | 19.000 | 6.000 | 2614 | 1053 | 0.2362 | 0.7480 | 626SS |
626DD | 626DD | 6.000 | 19.000 | 6.000 | 2614 | 1053 | 0.2362 | 0.7480 | 626DD |
626ZZ | 626ZZ | 6.000 | 19.000 | 6.000 | 2614 | 1053 | 0.2362 | 0.7480 | 626ZZ |
626 | 626 | 6.000 | 19.000 | 6.000 | 2614 | 1053 | 0.2362 | 0.7480 | 626 |
R-1760X2DD | 606DD | 6.000 | 17.000 | 6.000 | 2265 | 839 | 0.2362 | 0.6693 | R-1760X2DD |
R-1760X2KK | 606ZZ | 6.000 | 17.000 | 6.000 | 2265 | 839 | 0.2362 | 0.6693 | R-1760X2KK |
R-1760X2 | 606 | 6.000 | 17.000 | 6.000 | 2265 | 839 | 0.2362 | 0.6693 | R-1760X2 |
R-1660DD | - | 6.000 | 16.000 | 5.000 | 1735 | 671 | 0.2362 | 0.6299 | R-1660DD |
R-1660HH | - | 6.000 | 16.000 | 5.000 | 1735 | 671 | 0.2362 | 0.6299 | R-1660HH |
R-1560X13DD | 696DD | 6.000 | 15.000 | 5.000 | 1735 | 671 | 0.2362 | 0.5906 | R-1560X13DD |
R-1560X13KK | 696ZZ | 6.000 | 15.000 | 5.000 | 1735 | 671 | 0.2362 | 0.5906 | R-1560X13KK |
L-1360DD | - | 6.000 | 13.000 | 5.000 | 1083 | 438 | 0.2362 | 0.5118 | L-1360DD |
L-1360ZZ | - | 6.000 | 13.000 | 5.000 | 1083 | 438 | 0.2362 | 0.5118 | L-1360ZZ |
L-1360 | 686 | 6.000 | 13.000 | 3.500 | 1083 | 438 | 0.2362 | 0.5118 | L-1360 |
L-1260X2DD | - | 6.000 | 12.000 | 4.000 | 831 | 363 | 0.2362 | 0.4724 | L-1260X2DD |
L-1260ZZ | - | 6.000 | 12.000 | 4.000 | 831 | 363 | 0.2362 | 0.4724 | L-1260ZZ |
L-1260 | - | 6.000 | 12.000 | 3.000 | 831 | 363 | 0.2362 | 0.4724 | L-1260 |
L-1060SS | - | 6.000 | 10.000 | 3.000 | 457 | 194 | 0.2362 | 0.3937 | L-1060SS |
L-1060DD | - | 6.000 | 10.000 | 3.000 | 457 | 194 | 0.2362 | 0.3937 | L-1060DD |
L-1060ZZ | - | 6.000 | 10.000 | 3.000 | 457 | 194 | 0.2362 | 0.3937 | L-1060ZZ |
L-1060 | 676 | 6.000 | 10.000 | 2.500 | 457 | 194 | 0.2362 | 0.3937 | L-1060 |
635ZZ | 635ZZ | 5.000 | 19.000 | 6.000 | 2614 | 1053 | 0.1969 | 0.7480 | 635ZZ |
635 | 635 | 5.000 | 19.000 | 6.000 | 2614 | 1053 | 0.1969 | 0.7480 | 635 |
R-1650SS | 625SS | 5.000 | 16.000 | 5.000 | 1735 | 671 | 0.1969 | 0.6299 | R-1650SS |
R-1650DD | 625DD | 5.000 | 16.000 | 5.000 | 1735 | 671 | 0.1969 | 0.6299 | R-1650DD |
R-1650HH | 625ZZ | 5.000 | 16.000 | 5.000 | 1735 | 671 | 0.1969 | 0.6299 | R-1650HH |
R-1650 | 625 | 5.000 | 16.000 | 5.000 | 1735 | 671 | 0.1969 | 0.6299 | R-1650 |
R-1450ZZ | 605ZZ | 5.000 | 14.000 | 5.000 | 1329 | 508 | 0.1969 | 0.5512 | R-1450ZZ |
R-1450 | 605 | 5.000 | 14.000 | 5.000 | 1329 | 508 | 0.1969 | 0.5512 | R-1450 |
R-1350X2SS | 695SS | 5.000 | 13.000 | 4.000 | 1074 | 422 | 0.1969 | 0.5118 | R-1350X2SS |
R-1350X2DD | 695DD | 5.000 | 13.000 | 4.000 | 1074 | 422 | 0.1969 | 0.5118 | R-1350X2DD |
R-1350X2ZZ | 695ZZ | 5.000 | 13.000 | 4.000 | 1074 | 422 | 0.1969 | 0.5118 | R-1350X2ZZ |
R-1350DD | 695DD | 5.000 | 13.000 | 4.000 | 1074 | 422 | 0.1969 | 0.5118 | R-1350DD |
R-1350ZZ | 695ZZ | 5.000 | 13.000 | 4.000 | 1074 | 422 | 0.1969 | 0.5118 | R-1350ZZ |
R-1350 | 695 | 5.000 | 13.000 | 4.000 | 1074 | 422 | 0.1969 | 0.5118 | R-1350 |
L-1150ZZY04 | - | 5.000 | 11.000 | 4.000 | 714 | 276 | 0.1969 | 0.4331 | L-1150ZZY04 |
L-1150ZZ | - | 5.000 | 11.000 | 5.000 | 714 | 276 | 0.1969 | 0.4331 | L-1150ZZ |
L-1150 | 685 | 5.000 | 11.000 | 3.000 | 714 | 276 | 0.1969 | 0.4331 | L-1150 |
L-1050SS | - | 5.000 | 10.000 | 4.000 | 714 | 276 | 0.1969 | 0.3937 | L-1050SS |
L-1050ZZ | - | 5.000 | 10.000 | 4.000 | 714 | 276 | 0.1969 | 0.3937 | L-1050ZZ |
L-1050 | - | 5.000 | 10.000 | 3.000 | 714 | 276 | 0.1969 | 0.3937 | L-1050 |
L-950ZZ | - | 5.000 | 9.000 | 3.000 | 495 | 207 | 0.1969 | 0.3543 | L-950ZZ |
L-850ZZ | - | 5.000 | 8.000 | 2.500 | 274 | 130 | 0.1969 | 0.3150 | L-850ZZ |
L-850 | 675 | 5.000 | 8.000 | 2.000 | 274 | 130 | 0.1969 | 0.3150 | L-850 |
R-1640DD | 634DD | 4.000 | 16.000 | 5.000 | 1735 | 671 | 0.1575 | 0.6299 | R-1640DD |
R-1640HH | 634ZZ | 4.000 | 16.000 | 5.000 | 1735 | 671 | 0.1575 | 0.6299 | R-1640HH |
R-1640 | 634 | 4.000 | 16.000 | 5.000 | 1735 | 671 | 0.1575 | 0.6299 | R-1640 |
R-1340DD | 624DD | 4.000 | 13.000 | 5.000 | 1306 | 487 | 0.1575 | 0.5118 | R-1340DD |
R-1340HH | 624ZZ | 4.000 | 13.000 | 5.000 | 1306 | 487 | 0.1575 | 0.5118 | R-1340HH |
R-1340 | 624 | 4.000 | 13.000 | 5.000 | 1306 | 487 | 0.1575 | 0.5118 | R-1340 |
R-1240KK1 | 604ZZ | 4.000 | 12.000 | 4.000 | 959 | 347 | 0.1575 | 0.4724 | R-1240KK1 |
R-1240 | 604 | 4.000 | 12.000 | 4.000 | 959 | 347 | 0.1575 | 0.4724 | R-1240 |
R-1140ZZ | 694ZZ | 4.000 | 11.000 | 4.000 | 714 | 276 | 0.1575 | 0.4331 | R-1140ZZ |
R-1140 | 694 | 4.000 | 11.000 | 4.000 | 714 | 276 | 0.1575 | 0.4331 | R-1140 |
L-1040X2ZZ | - | 4.000 | 10.000 | 4.000 | 708 | 266 | 0.1575 | 0.3937 | L-1040X2ZZ |
L-1040X2 | - | 4.000 | 10.000 | 3.000 | 708 | 266 | 0.1575 | 0.3937 | L-1040X2 |
L-940ZZ | - | 4.000 | 9.000 | 4.000 | 641 | 226 | 0.1575 | 0.3543 | L-940ZZ |
L-940 | 684 | 4.000 | 9.000 | 2.500 | 641 | 226 | 0.1575 | 0.3543 | L-940 |
L-840ZZ | - | 4.000 | 8.000 | 3.000 | 391 | 140 | 0.1575 | 0.3150 | L-840ZZ |
L-740ZZ | 674ZZ | 4.000 | 7.000 | 2.500 | 252 | 106 | 0.1575 | 0.2756 | L-740ZZ |
R-1030ZZ | 623ZZ | 3.000 | 10.000 | 4.000 | 641 | 226 | 0.1181 | 0.3937 | R-1030ZZ |
R-1030 | 623 | 3.000 | 10.000 | 4.000 | 641 | 226 | 0.1181 | 0.3937 | R-1030 |
R-930ZZY04 | - | 3.000 | 9.000 | 4.000 | 634 | 219 | 0.1181 | 0.3543 | R-930ZZY04 |
R-830X10ZZ | - | 3.000 | 8.000 | 4.000 | 553 | 176 | 0.1181 | 0.3150 | R-830X10ZZ |
R-830ZZ | - | 3.000 | 8.000 | 4.000 | 553 | 176 | 0.1181 | 0.3150 | R-830ZZ |
R-830 | 693 | 3.000 | 8.000 | 3.000 | 553 | 176 | 0.1181 | 0.3150 | R-830 |
L-730ZZ | - | 3.000 | 7.000 | 3.000 | 384 | 129 | 0.1181 | 0.2756 | L-730ZZ |
L-730 | 683 | 3.000 | 7.000 | 2.000 | 384 | 129 | 0.1181 | 0.2756 | L-730 |
L-630ZZ | - | 3.000 | 6.000 | 2.500 | 206 | 73 | 0.1181 | 0.2362 | L-630ZZ |
L-630 | 673 | 3.000 | 6.000 | 2.000 | 206 | 73 | 0.1181 | 0.2362 | L-630 |
R-825ZZ | - | 2.500 | 8.000 | 4.000 | 553 | 176 | 0.0984 | 0.3150 | R-825ZZ |
R-725ZZ | - | 2.500 | 7.000 | 3.500 | 380 | 126 | 0.0984 | 0.2756 | R-725ZZ |
L-625ZZ | - | 2.500 | 6.000 | 2.600 | 206 | 73 | 0.0984 | 0.2362 | L-625ZZ |
R-720ZZ | - | 2.000 | 7.000 | 3.500 | 380 | 126 | 0.0787 | 0.2756 | R-720ZZ |
R-620ZZY52 | - | 2.000 | 6.000 | 2.500 | 330 | 99 | 0.0787 | 0.2362 | R-620ZZY52 |
R-620W52 | - | 2.000 | 6.000 | 2.500 | 330 | 99 | 0.0787 | 0.2362 | R-620W52 |
R-620ZZ | - | 2.000 | 6.000 | 3.000 | 330 | 99 | 0.0787 | 0.2362 | R-620ZZ |
L-520X9ZZW52 | - | 2.000 | 5.000 | 2.500 | 186 | 58 | 0.0787 | 0.1969 | L-520X9ZZW52 |
L-520ZZW52 | - | 2.000 | 5.000 | 2.500 | 187 | 59 | 0.0787 | 0.1969 | L-520ZZW52 |
L-520W52 | - | 2.000 | 5.000 | 2.500 | 187 | 59 | 0.0787 | 0.1969 | L-520W52 |
L-520ZZ | - | 2.000 | 5.000 | 2.300 | 187 | 59 | 0.0787 | 0.1969 | L-520ZZ |
L-520 | 682 | 2.000 | 5.000 | 1.500 | 187 | 59 | 0.0787 | 0.1969 | L-520 |
L-415X5ZZ | 68/1.5ZZ | 1.500 | 4.000 | 2.000 | 113 | 34 | 0.0591 | 0.1575 | L-415X5ZZ |
L-415 | 68/1.5 | 1.500 | 4.000 | 1.200 | 125 | 38 | 0.0591 | 0.1575 | L-415 |
L-310 | 681 | 1.000 | 3.000 | 1.000 | 80 | 23 | 0.0394 | 0.1181 | L-310 |
Flanged deep groove ball bearings
NMB Parts No. | ISO/JIS | Inner Diameter (d) [mm] |
Outer Diameter (D) [mm] |
Width (B) [mm] |
Dynamic Load Rating (Cr) [N] |
Static Load Rating (Cor) [N] |
Inner Diameter (d) [in] |
Outer Diameter (D) [in] |
CAD Data |
---|---|---|---|---|---|---|---|---|---|
RIF-1438DD | - | 9.525 | 22.225 | 7.142 | 3297 | 1368 | 0.3750 | 0.8750 | RIF-1438DD |
RIF-1438KK | - | 9.525 | 22.225 | 7.142 | 3297 | 1368 | 0.3750 | 0.8750 | RIF-1438KK |
DDRIF-1438ZZ | - | 9.525 | 22.225 | 7.142 | 3297 | 1368 | 0.3750 | 0.8750 | DDRIF-1438ZZ |
DDRIF-8516ZZ | - | 7.938 | 12.700 | 3.967 | 878 | 419 | 0.3125 | 0.5000 | DDRIF-8516ZZ |
DDRIF-8516 | - | 7.938 | 12.700 | 3.967 | 878 | 419 | 0.3125 | 0.5000 | DDRIF-8516 |
RF-4HH | - | 6.350 | 15.875 | 4.978 | 1470 | 599 | 0.2500 | 0.6250 | RF-4HH |
DDRF-4HH | - | 6.350 | 15.875 | 4.978 | 1470 | 599 | 0.2500 | 0.6250 | DDRF-4HH |
DDRIF-814ZZ | - | 6.350 | 12.700 | 4.762 | 828 | 374 | 0.2500 | 0.5000 | DDRIF-814ZZ |
DDRIF-814 | - | 6.350 | 12.700 | 3.175 | 828 | 374 | 0.2500 | 0.5000 | DDRIF-814 |
DDRIF-614ZZ | - | 6.350 | 9.525 | 3.175 | 417 | 205 | 0.2500 | 0.3750 | DDRIF-614ZZ |
DDRIF-614 | - | 6.350 | 9.525 | 3.175 | 417 | 205 | 0.2500 | 0.3750 | DDRIF-614 |
DDRF-3ZZ | - | 4.762 | 12.700 | 4.978 | 1306 | 487 | 0.1875 | 0.5000 | DDRF-3ZZ |
DDRF-3 | - | 4.762 | 12.700 | 3.967 | 1306 | 487 | 0.1875 | 0.5000 | DDRF-3 |
DDRIF-6632ZZ | - | 4.762 | 9.525 | 3.175 | 712 | 271 | 0.1875 | 0.3750 | DDRIF-6632ZZ |
DDRIF-6632 | - | 4.762 | 9.525 | 3.175 | 712 | 271 | 0.1875 | 0.3750 | DDRIF-6632 |
DDRIF-5632ZZ | - | 4.762 | 7.938 | 3.175 | 391 | 142 | 0.1875 | 0.3125 | DDRIF-5632ZZ |
DDRIF-5632 | - | 4.762 | 7.938 | 2.779 | 391 | 142 | 0.1875 | 0.3125 | DDRIF-5632 |
DDRIF-5532ZZ | - | 3.967 | 7.938 | 3.175 | 391 | 142 | 0.1562 | 0.3125 | DDRIF-5532ZZ |
DDRIF-618ZZ | - | 3.175 | 9.525 | 3.571 | 563 | 183 | 0.1250 | 0.3750 | DDRIF-618ZZ |
DDRIF-618 | - | 3.175 | 9.525 | 2.779 | 563 | 183 | 0.1250 | 0.3750 | DDRIF-618 |
DDRF-2ZZ | - | 3.175 | 9.525 | 3.967 | 641 | 226 | 0.1250 | 0.3750 | DDRF-2ZZ |
DDRF-2 | - | 3.175 | 9.525 | 3.967 | 641 | 226 | 0.1250 | 0.3750 | DDRF-2 |
DDRIF-518ZZ | - | 3.175 | 7.938 | 3.571 | 563 | 183 | 0.1250 | 0.3125 | DDRIF-518ZZ |
DDRIF-518 | - | 3.175 | 7.938 | 2.779 | 563 | 183 | 0.1250 | 0.3125 | DDRIF-518 |
DDRIF-418ZZ | - | 3.175 | 6.350 | 2.779 | 285 | 97 | 0.1250 | 0.2500 | DDRIF-418ZZ |
DDRIF-418 | - | 3.175 | 6.350 | 2.380 | 285 | 97 | 0.1250 | 0.2500 | DDRIF-418 |
DDRIF-5ZZ | - | 2.380 | 7.938 | 3.571 | 563 | 183 | 0.0937 | 0.3125 | DDRIF-5ZZ |
DDRIF-5 | - | 2.380 | 7.938 | 2.779 | 563 | 183 | 0.0937 | 0.3125 | DDRIF-5 |
DDRIF-3332ZZ | - | 2.380 | 4.762 | 2.380 | 187 | 59 | 0.0937 | 0.1875 | DDRIF-3332ZZ |
DDRIF-3332 | - | 2.380 | 4.762 | 1.588 | 187 | 59 | 0.0937 | 0.1875 | DDRIF-3332 |
DDRIF-4ZZ | - | 1.984 | 6.350 | 3.571 | 330 | 99 | 0.0781 | 0.2500 | DDRIF-4ZZ |
DDRIF-4 | - | 1.984 | 6.350 | 2.380 | 330 | 99 | 0.0781 | 0.2500 | DDRIF-4 |
DDRIF-3 | - | 1.397 | 4.762 | 1.984 | 264 | 71 | 0.0550 | 0.1875 | DDRIF-3 |
DDRIF-2X2 | - | 1.016 | 3.175 | 1.191 | 106 | 28 | 0.0400 | 0.1250 | DDRIF-2X2 |
DDRF-2210X2HH | F6900ZZ | 10.000 | 22.000 | 6.000 | 2697 | 1273 | 0.3937 | 0.8661 | DDRF-2210X2HH |
DDLF-1910ZZ | - | 10.000 | 19.000 | 7.000 | 2123 | 985 | 0.3937 | 0.7480 | DDLF-1910ZZ |
DDLF-1790ZZ | - | 9.000 | 17.000 | 5.000 | 1724 | 813 | 0.3543 | 0.6693 | DDLF-1790ZZ |
DDLF-1790 | F689 | 9.000 | 17.000 | 4.000 | 1724 | 813 | 0.3543 | 0.6693 | DDLF-1790 |
RF-2280HH | F608ZZ | 8.000 | 22.000 | 7.000 | 3297 | 1368 | 0.3150 | 0.8661 | RF-2280HH |
RF-2280 | F608 | 8.000 | 22.000 | 7.000 | 3297 | 1368 | 0.3150 | 0.8661 | RF-2280 |
DDRF-2280HH | F608ZZ | 8.000 | 22.000 | 7.000 | 3297 | 1368 | 0.3150 | 0.8661 | DDRF-2280HH |
DDRF-2280 | F608 | 8.000 | 22.000 | 7.000 | 3297 | 1368 | 0.3150 | 0.8661 | DDRF-2280 |
DDRF-1980DD | F698DD | 8.000 | 19.000 | 6.000 | 2463 | 1059 | 0.3150 | 0.7480 | DDRF-1980DD |
DDRF-1980ZZ | F698ZZ | 8.000 | 19.000 | 6.000 | 2240 | 912 | 0.3150 | 0.7480 | DDRF-1980ZZ |
DDRF-1980 | F698 | 8.000 | 19.000 | 6.000 | 2240 | 912 | 0.3150 | 0.7480 | DDRF-1980 |
LF-1680HH | - | 8.000 | 16.000 | 5.000 | 1606 | 712 | 0.3150 | 0.6299 | LF-1680HH |
DDLF-1680HH | - | 8.000 | 16.000 | 5.000 | 1606 | 712 | 0.3150 | 0.6299 | DDLF-1680HH |
DDLF-1680 | F688 | 8.000 | 16.000 | 4.000 | 1606 | 712 | 0.3150 | 0.6299 | DDLF-1680 |
LF-1480DD | - | 8.000 | 14.000 | 4.000 | 819 | 386 | 0.3150 | 0.5512 | LF-1480DD |
LF-1480X3ZZ | - | 8.000 | 14.000 | 4.000 | 878 | 419 | 0.3150 | 0.5512 | LF-1480X3ZZ |
DDLF-1480ZZ | - | 8.000 | 14.000 | 4.000 | 819 | 386 | 0.3150 | 0.5512 | DDLF-1480ZZ |
DDLF-1480 | - | 8.000 | 14.000 | 3.500 | 819 | 386 | 0.3150 | 0.5512 | DDLF-1480 |
DDLF-1280DD | - | 8.000 | 12.000 | 3.500 | 506 | 249 | 0.3150 | 0.4724 | DDLF-1280DD |
DDLF-1280ZZ | - | 8.000 | 12.000 | 3.500 | 506 | 249 | 0.3150 | 0.4724 | DDLF-1280ZZ |
DDLF-1280 | F678 | 8.000 | 12.000 | 2.500 | 506 | 249 | 0.3150 | 0.4724 | DDLF-1280 |
DDRF-2270HH | F627ZZ | 7.000 | 22.000 | 7.000 | 3297 | 1368 | 0.2756 | 0.8661 | DDRF-2270HH |
DDRF-2270 | F627 | 7.000 | 22.000 | 7.000 | 3297 | 1368 | 0.2756 | 0.8661 | DDRF-2270 |
DDRF-1970DD | F607DD | 7.000 | 19.000 | 6.000 | 2240 | 912 | 0.2756 | 0.7480 | DDRF-1970DD |
DDRF-1970ZZ | F607ZZ | 7.000 | 19.000 | 6.000 | 2240 | 912 | 0.2756 | 0.7480 | DDRF-1970ZZ |
DDLF-1470ZZ | - | 7.000 | 14.000 | 5.000 | 1175 | 511 | 0.2756 | 0.5512 | DDLF-1470ZZ |
DDLF-1470 | F687 | 7.000 | 14.000 | 3.500 | 1175 | 511 | 0.2756 | 0.5512 | DDLF-1470 |
DDLF-1370ZZ | - | 7.000 | 13.000 | 4.000 | 880 | 414 | 0.2756 | 0.5118 | DDLF-1370ZZ |
DDLF-1370 | - | 7.000 | 13.000 | 3.000 | 880 | 414 | 0.2756 | 0.5118 | DDLF-1370 |
DDLF-1170ZZ | - | 7.000 | 11.000 | 3.000 | 449 | 199 | 0.2756 | 0.4331 | DDLF-1170ZZ |
DDLF-1170 | F677 | 7.000 | 11.000 | 2.500 | 449 | 199 | 0.2756 | 0.4331 | DDLF-1170 |
RF-1960ZZ | F626ZZ | 6.000 | 19.000 | 6.000 | 2805 | 1060 | 0.2362 | 0.7480 | RF-1960ZZ |
DDRF-1960ZZ | F626ZZ | 6.000 | 19.000 | 6.000 | 2805 | 1060 | 0.2362 | 0.7480 | DDRF-1960ZZ |
DDRF-1960 | F626 | 6.000 | 19.000 | 6.000 | 2805 | 1060 | 0.2362 | 0.7480 | DDRF-1960 |
RF-1760X2ZZ | F606ZZ | 6.000 | 17.000 | 6.000 | 2265 | 839 | 0.2362 | 0.6693 | RF-1760X2ZZ |
DDRF-1760X2ZZ | F606ZZ | 6.000 | 17.000 | 6.000 | 2265 | 839 | 0.2362 | 0.6693 | DDRF-1760X2ZZ |
DDRF-1760X2 | F606 | 6.000 | 17.000 | 6.000 | 2265 | 839 | 0.2362 | 0.6693 | DDRF-1760X2 |
DDRF-1560ZZ | F696ZZ | 6.000 | 15.000 | 5.000 | 1735 | 671 | 0.2362 | 0.5906 | DDRF-1560ZZ |
DDRF-1560 | F696 | 6.000 | 15.000 | 5.000 | 1735 | 671 | 0.2362 | 0.5906 | DDRF-1560 |
LF-1360ZZ | - | 6.000 | 13.000 | 5.000 | 1083 | 438 | 0.2362 | 0.5118 | LF-1360ZZ |
DDLF-1360ZZ | - | 6.000 | 13.000 | 5.000 | 1083 | 438 | 0.2362 | 0.5118 | DDLF-1360ZZ |
DDLF-1360 | F686 | 6.000 | 13.000 | 3.500 | 1083 | 438 | 0.2362 | 0.5118 | DDLF-1360 |
LF-1260ZZ | - | 6.000 | 12.000 | 4.000 | 831 | 363 | 0.2362 | 0.4724 | LF-1260ZZ |
DDLF-1260ZZ | - | 6.000 | 12.000 | 4.000 | 831 | 363 | 0.2362 | 0.4724 | DDLF-1260ZZ |
DDLF-1260 | - | 6.000 | 12.000 | 3.000 | 831 | 363 | 0.2362 | 0.4724 | DDLF-1260 |
LF-1060ZZ | - | 6.000 | 10.000 | 3.000 | 457 | 194 | 0.2362 | 0.3937 | LF-1060ZZ |
DDLF-1060ZZ | - | 6.000 | 10.000 | 3.000 | 457 | 194 | 0.2362 | 0.3937 | DDLF-1060ZZ |
DDLF-1060 | F676 | 6.000 | 10.000 | 2.500 | 457 | 194 | 0.2362 | 0.3937 | DDLF-1060 |
DDRF-1950ZZ | F635ZZ | 5.000 | 19.000 | 6.000 | 2805 | 1060 | 0.1969 | 0.7480 | DDRF-1950ZZ |
DDRF-1950 | F635 | 5.000 | 19.000 | 6.000 | 2805 | 1060 | 0.1969 | 0.7480 | DDRF-1950 |
DDRF-1650HH | F625ZZ | 5.000 | 16.000 | 5.000 | 1735 | 671 | 0.1969 | 0.6299 | DDRF-1650HH |
DDRF-1650 | F625 | 5.000 | 16.000 | 5.000 | 1735 | 671 | 0.1969 | 0.6299 | DDRF-1650 |
RF-1450ZZ | F605ZZ | 5.000 | 14.000 | 5.000 | 1329 | 508 | 0.1969 | 0.5512 | RF-1450ZZ |
DDRF-1450ZZ | F605ZZ | 5.000 | 14.000 | 5.000 | 1329 | 508 | 0.1969 | 0.5512 | DDRF-1450ZZ |
DDRF-1450 | F605 | 5.000 | 14.000 | 5.000 | 1329 | 508 | 0.1969 | 0.5512 | DDRF-1450 |
DDRF-1350ZZ | F695ZZ | 5.000 | 13.000 | 4.000 | 1074 | 422 | 0.1969 | 0.5118 | DDRF-1350ZZ |
DDRF-1350 | F695 | 5.000 | 13.000 | 4.000 | 1074 | 422 | 0.1969 | 0.5118 | DDRF-1350 |
LF-1150ZZ | - | 5.000 | 11.000 | 5.000 | 714 | 276 | 0.1969 | 0.4331 | LF-1150ZZ |
DDLF-1150ZZ | - | 5.000 | 11.000 | 5.000 | 714 | 276 | 0.1969 | 0.4331 | DDLF-1150ZZ |
DDLF-1150 | F685 | 5.000 | 11.000 | 3.000 | 714 | 276 | 0.1969 | 0.4331 | DDLF-1150 |
LF-1050ZZ | - | 5.000 | 10.000 | 4.000 | 714 | 276 | 0.1969 | 0.3937 | LF-1050ZZ |
DDLF-1050ZZ | - | 5.000 | 10.000 | 4.000 | 714 | 276 | 0.1969 | 0.3937 | DDLF-1050ZZ |
DDLF-1050 | - | 5.000 | 10.000 | 3.000 | 714 | 276 | 0.1969 | 0.3937 | DDLF-1050 |
DDLF-950ZZ | - | 5.000 | 9.000 | 3.000 | 495 | 207 | 0.1969 | 0.3543 | DDLF-950ZZ |
DDLF-950 | - | 5.000 | 9.000 | 2.500 | 495 | 207 | 0.1969 | 0.3543 | DDLF-950 |
DDLF-850ZZ | - | 5.000 | 8.000 | 2.500 | 274 | 130 | 0.1969 | 0.3150 | DDLF-850ZZ |
DDLF-850 | F675 | 5.000 | 8.000 | 2.000 | 274 | 130 | 0.1969 | 0.3150 | DDLF-850 |
DDRF-1640ZZ | F634ZZ | 4.000 | 16.000 | 5.000 | 1735 | 671 | 0.1575 | 0.6299 | DDRF-1640ZZ |
DDRF-1340ZZ | F624ZZ | 4.000 | 13.000 | 5.000 | 1306 | 487 | 0.1575 | 0.5118 | DDRF-1340ZZ |
DDRF-1340 | F624 | 4.000 | 13.000 | 5.000 | 1306 | 487 | 0.1575 | 0.5118 | DDRF-1340 |
DDRF-1240ZZ | F604ZZ | 4.000 | 12.000 | 4.000 | 959 | 347 | 0.1575 | 0.4724 | DDRF-1240ZZ |
DDRF-1240 | F604 | 4.000 | 12.000 | 4.000 | 959 | 347 | 0.1575 | 0.4724 | DDRF-1240 |
DDRF-1140ZZ | F694ZZ | 4.000 | 11.000 | 4.000 | 714 | 276 | 0.1575 | 0.4331 | DDRF-1140ZZ |
DDLF-1040ZZ | - | 4.000 | 10.000 | 4.000 | 708 | 266 | 0.1575 | 0.3937 | DDLF-1040ZZ |
DDLF-1040 | - | 4.000 | 10.000 | 3.000 | 708 | 266 | 0.1575 | 0.3937 | DDLF-1040 |
DDLF-940ZZ | - | 4.000 | 9.000 | 4.000 | 641 | 226 | 0.1575 | 0.3543 | DDLF-940ZZ |
DDLF-940 | F684 | 4.000 | 9.000 | 2.500 | 641 | 226 | 0.1575 | 0.3543 | DDLF-940 |
DDLF-840ZZ | - | 4.000 | 8.000 | 3.000 | 391 | 140 | 0.1575 | 0.3150 | DDLF-840ZZ |
DDLF-840 | - | 4.000 | 8.000 | 2.000 | 391 | 140 | 0.1575 | 0.3150 | DDLF-840 |
DDLF-740ZZ | - | 4.000 | 7.000 | 2.500 | 252 | 106 | 0.1575 | 0.2756 | DDLF-740ZZ |
DDLF-740 | F674 | 4.000 | 7.000 | 2.000 | 252 | 106 | 0.1575 | 0.2756 | DDLF-740 |
DDRF-1030ZZ | F623ZZ | 3.000 | 10.000 | 4.000 | 641 | 226 | 0.1181 | 0.3937 | DDRF-1030ZZ |
DDRF-930ZZ | - | 3.000 | 9.000 | 5.000 | 634 | 219 | 0.1181 | 0.3543 | DDRF-930ZZ |
DDRF-830ZZ | - | 3.000 | 8.000 | 4.000 | 553 | 176 | 0.1181 | 0.3150 | DDRF-830ZZ |
DDRF-830 | F693 | 3.000 | 8.000 | 3.000 | 553 | 176 | 0.1181 | 0.3150 | DDRF-830 |
DDLF-730ZZ | - | 3.000 | 7.000 | 3.000 | 384 | 129 | 0.1181 | 0.2756 | DDLF-730ZZ |
DDLF-730 | F683 | 3.000 | 7.000 | 2.000 | 384 | 129 | 0.1181 | 0.2756 | DDLF-730 |
DDLF-630ZZ | - | 3.000 | 6.000 | 2.500 | 206 | 73 | 0.1181 | 0.2362 | DDLF-630ZZ |
DDLF-630 | F673 | 3.000 | 6.000 | 2.000 | 206 | 73 | 0.1181 | 0.2362 | DDLF-630 |
DDRF-825ZZ | - | 2.500 | 8.000 | 4.000 | 553 | 176 | 0.0984 | 0.3150 | DDRF-825ZZ |
DDRF-725ZZ | - | 2.500 | 7.000 | 3.500 | 380 | 126 | 0.0984 | 0.2756 | DDRF-725ZZ |
DDLF-625ZZ | - | 2.500 | 6.000 | 2.600 | 206 | 73 | 0.0984 | 0.2362 | DDLF-625ZZ |
DDRF-720ZZ | - | 2.000 | 7.000 | 3.500 | 380 | 126 | 0.0787 | 0.2756 | DDRF-720ZZ |
DDRF-620ZZ | - | 2.000 | 6.000 | 3.000 | 330 | 99 | 0.0787 | 0.2362 | DDRF-620ZZ |
DDRF-620 | F692 | 2.000 | 6.000 | 2.300 | 279 | 89 | 0.0787 | 0.2362 | DDRF-620 |
DDLF-520ZZ | - | 2.000 | 5.000 | 2.300 | 187 | 59 | 0.0787 | 0.1969 | DDLF-520ZZ |
DDLF-520 | F682 | 2.000 | 5.000 | 1.500 | 187 | 59 | 0.0787 | 0.1969 | DDLF-520 |
DDRF-615ZZ | - | 1.500 | 6.000 | 3.000 | 324 | 97 | 0.0591 | 0.2362 | DDRF-615ZZ |
DDRF-515ZZ | - | 1.500 | 5.000 | 2.600 | 184 | 57 | 0.0591 | 0.1969 | DDRF-515ZZ |
DDRF-515 | F69/1.5 | 1.500 | 5.000 | 2.000 | 184 | 57 | 0.0591 | 0.1969 | DDRF-515 |
DDLF-415ZZ | - | 1.500 | 4.000 | 2.000 | 125 | 38 | 0.0591 | 0.1575 | DDLF-415ZZ |
DDLF-415 | F68/1.5 | 1.500 | 4.000 | 1.200 | 125 | 38 | 0.0591 | 0.1575 | DDLF-415 |
DDLF-310 | F681 | 1.000 | 3.000 | 1.000 | 80 | 23 | 0.0394 | 0.1181 | DDLF-310 |
Deep groove ball bearings with locating snap ring
NMB Parts No. | ISO/JIS | Inner Diameter (d) [mm] |
Outer Diameter (D) [mm] |
Width (B) [mm] |
Dynamic Load Rating (Cr) [N] |
Static Load Rating (Cor) [N] |
Inner Diameter (d) [in] |
Outer Diameter (D) [in] |
CAD Data |
---|---|---|---|---|---|---|---|---|---|
RNR-2412X3KK | 6901ZZNR | 12.000 | 24.000 | 6.000 | 3082 | 1433 | 0.4724 | 0.9449 | RNR-2412X3KK |
RNR-2210X9KKSD21 | 6900ZZNR | 10.000 | 22.000 | 6.000 | 2697 | 1273 | 0.3937 | 0.8661 | RNR-2210X9KKSD21 |
608DDNRSD06 | 608DDNR | 8.000 | 22.000 | 7.000 | 3297 | 1368 | 0.3150 | 0.8661 | 608DDNRSD06 |
608ZZNRSD06 | 608ZZNR | 8.000 | 22.000 | 7.000 | 3297 | 1368 | 0.3150 | 0.8661 | 608ZZNRSD06 |
LNR-1680DD | - | 8.000 | 16.000 | 5.000 | 1606 | 712 | 0.3150 | 0.6299 | LNR-1680DD |
LNR-1680KK | - | 8.000 | 16.000 | 5.000 | 1606 | 712 | 0.3150 | 0.6299 | LNR-1680KK |
RNR-4KK | - | 6.350 | 15.875 | 4.978 | 1470 | 599 | 0.2500 | 0.6250 | RNR-4KK |
626DDNR | 626DDNR | 6.000 | 19.000 | 6.000 | 2614 | 1053 | 0.2362 | 0.7480 | 626DDNR |
626ZZNR | 626ZZNR | 6.000 | 19.000 | 6.000 | 2614 | 1053 | 0.2362 | 0.7480 | 626ZZNR |
RNR-1760X2DD | 606DDNR | 6.000 | 17.000 | 6.000 | 2265 | 839 | 0.2362 | 0.6693 | RNR-1760X2DD |
RNR-1760X2ZZ | 606ZZNR | 6.000 | 17.000 | 6.000 | 2265 | 839 | 0.2362 | 0.6693 | RNR-1760X2ZZ |
RNR-1560DD | 696DDNR | 6.000 | 15.000 | 5.000 | 1735 | 671 | 0.2362 | 0.5906 | RNR-1560DD |
RNR-1560ZZ | 696ZZNR | 6.000 | 15.000 | 5.000 | 1735 | 671 | 0.2362 | 0.5906 | RNR-1560ZZ |
LNR-1360X3ZZ | 686ZZNR | 6.000 | 13.000 | 5.000 | 831 | 363 | 0.2362 | 0.5118 | LNR-1360X3ZZ |
RNR-1350DD | 695DDNR | 5.000 | 13.000 | 4.000 | 1074 | 422 | 0.1969 | 0.5118 | RNR-1350DD |
RNR-1350ZZ | 695ZZNR | 5.000 | 13.000 | 4.000 | 1074 | 422 | 0.1969 | 0.5118 | RNR-1350ZZ |
Rotary Components
FDB Motor
Parts | Rated Voltage [V] |
Rated Speed [rpm] |
Power at rated speed [W] |
Friction Torque at rated speed [mN・m] |
Current at rated Speed (without load) [A] |
|
---|---|---|---|---|---|---|
BLDC FDB SP2B | 5 | 3600 | 0.45 | 1.19 | 0.18 |
Fan Motors
AC fan motors > AC fan motors
AC fan motors
Parts | Size (W) [mm] |
Size (H) [mm] |
Thickness(L) [mm] |
Rating Voltage [V] |
Max. Air Flow lower limit [m3/min] |
Max. Air Flow upper limit [m3/min] |
Max. Static Pressure lower limit [Pa] |
Max. Static Pressure upper limit [Pa] |
|
---|---|---|---|---|---|---|---|---|---|
11938SB | 119 | 119 | 38 | 100, 115, 200, 220, 230, 240 | 2.60 | 3.00 | 94.0 | 100.0 | |
11938MB Special Edition | 119 | 119 | 38 | 100, 115, 200, 220, 230, 240 | 2.50 | 2.90 | 63.8 | 76.5 | |
11938MB | 119 | 119 | 38 | 100, 115, 200, 220, 230, 240 | 2.50 | 2.90 | 63.8 | 76.5 | |
11925PB | 119 | 119 | 25 | 100, 115, 200, 220, 230, 240 | 1.70 | 2.00 | 41.2 | 41.2 | |
09238SB | 92 | 92 | 38 | 100, 115, 200, 220, 230, 240 | 1.05 | 1.25 | 63.0 | 80.0 | |
09225PB | 92 | 92 | 25 | 100, 115, 200, 220, 230, 240 | 0.80 | 0.98 | 43.1 | 60.9 | |
08038PB | 80 | 80 | 38 | 100, 115, 200, 220, 230, 240 | 0.75 | 0.90 | 34.4 | 49.1 | |
08025MB | 80 | 80 | 25 | 100, 115, 200, 220, 230, 240 | 0.57 | 0.68 | 39.0 | 55.0 | |
06030PB | 60 | 60 | 30 | 100, 115 | 0.20 | 0.26 | 13.7 | 22.6 |
AC fan motors for industrial use
Parts | Power lower limit [W] |
Power upper limit [W] |
rated speed lower limit [min-1] |
rated speed upper limit [min-1] |
Max. Air Flow lower limit [m3/min] |
Max. Air Flow upper limit [m3/min] |
Max. Static Pressure lower limit [Pa] |
Max. Static Pressure upper limit [Pa] |
---|---|---|---|---|---|---|---|---|
PT13839 | 73 | 114 | 1350 | 1600 | 26.20 | 34.30 | 143.0 | 196.0 |
PT9833 | 103 | 190 | 2600 | 3100 | 17.70 | 23.50 | 166.0 | 305.0 |
PT8330 | 35 | 82 | 2500 | 3050 | 12.00 | 14.30 | 108.0 | 244.0 |
PT7126 | 37 | 75 | 2660 | 3250 | 7.60 | 10.00 | 130.0 | 220.0 |
RT6925 | 49 | 95 | 2450 | 3250 | 4.00 | 5.50 | 240.0 | 365.0 |
RT6323 | 35 | 58 | 2050 | 2900 | 3.10 | 4.20 | 170.0 | 243.0 |
PT5921 | 22 | 33 | 2500 | 3200 | 3.30 | 4.50 | 90.0 | 156.0 |
RT5318 | 27 | 35 | 2450 | 2950 | 1.60 | 2.30 | 155.0 | 223.0 |
PT4720 | 25 | 30 | 2550 | 3050 | 1.70 | 2.70 | 48.0 | 70.0 |
DC fan motors
General purpose
Parts | Size (W) [mm] |
Size (H) [mm] |
Thickness(L) [mm] |
Rating Voltage [V] |
Max. Air Flow lower limit [m3/min] |
Max. Air Flow upper limit [m3/min] |
Max. Static Pressure lower limit [Pa] |
Max. Static Pressure upper limit [Pa] |
|
---|---|---|---|---|---|---|---|---|---|
11938KA | 119 | 119 | 38 | 12, 24, 48 | 3.070 | 3.680 | 68.1 | 110.0 | |
11925SA | 119 | 119 | 25 | 12, 24 | 1.900 | 3.630 | 28.5 | 89.0 | |
09225SA | 92 | 92 | 25 | 12, 24 | 1.130 | 1.840 | 29.0 | 73.0 | |
08025SA | 80 | 80 | 25 | 12, 24 | 0.860 | 1.700 | 21.5 | 82.0 | |
06025SA | 60 | 60 | 25 | 12, 24 | 0.480 | 1.070 | 35.0 | 158.5 | |
06015KA | 60 | 60 | 15 | 12, 24 | 0.400 | 0.520 | 31.3 | 51.2 |
Industrial
Parts | Size (W) [mm] |
Size (H) [mm] |
Thickness(L) [mm] |
Rating Voltage [V] |
Max. Air Flow lower limit [m3/min] |
Max. Air Flow upper limit [m3/min] |
Max. Static Pressure lower limit [Pa] |
Max. Static Pressure upper limit [Pa] |
|
---|---|---|---|---|---|---|---|---|---|
06025VA | 60 | 60 | 25 | 24 | 0.680 | 1.110 | 107.0 | 244.0 | |
06020VA | 60 | 60 | 20 | 24 | 0.700 | 0.700 | 100.0 | 100.0 | |
06015VA | 60 | 60 | 15 | 12, 24 | 0.450 | 0.550 | 48.3 | 67.7 | |
04020VA | 40 | 40 | 20 | 12, 24 | 0.250 | 0.380 | 58.8 | 165.0 |
Semiconductors
Power Supply IC > Reset ICs
Series name | Absolute maximum rating [V] |
Recommended operating voltage Min. [V] |
Recommended operating voltage Max. [V] |
Detection voltage Min. [V] |
Detection voltage Max. [V] |
Detection voltage accuracy [%] |
Consumption current [μA] |
---|---|---|---|---|---|---|---|
PST810 | 7.0 | 1.10 | 6.00 | 1.6 | 5.0 | ±1 | 0.50 |
PST809 | 7.0 | 1.10 | 6.00 | 1.6 | 5.0 | ±1 | 0.50 |
PST804 | 7.0 | 1.10 | 6.00 | 1.6 | 5.0 | ±1 | 0.50 |
PST803 | 7.0 | 1.10 | 6.00 | 1.6 | 5.0 | ±1 | 0.50 |
PST88xR | 6.0 | 1.20 | 5.50 | 1.6 | 4.6 | ±1.5 | 1.00 |
PST87xR | 6.0 | 1.20 | 5.50 | 1.6 | 4.6 | ±1.5 | 1.00 |
PST88xA | 6.0 | 1.20 | 5.50 | 1.6 | 4.6 | ±1.5 | 1.00 |
PST87xA | 6.0 | 1.20 | 5.50 | 1.6 | 4.6 | ±1.5 | 1.00 |
IC-PST598 | 12.0 | 12.00 | 2.3 | 4.5 | ±15mV | 15.00 | |
IC-PST597 | 12.0 | 12.00 | 2.3 | 4.5 | ±15mV | 15.00 | |
IC-PST596 | 12.0 | 12.00 | 2.3 | 4.5 | ±15mV | 15.00 | |
PST11D | 40.0 | 2.70 | 20.00 | 5.0 | 10.0 | ±2 | 1.70 |
PST114 | 40.0 | 2.70 | 20.00 | 5.0 | 10.0 | ±2 | 1.70 |
PST854A | 6.5 | 0.70 | 6.00 | 0.8 | 5.2 | ±1 | 0.35 |
PST853A | 6.5 | 0.70 | 6.00 | 0.8 | 5.2 | ±1 | 0.35 |
PST894R | 6.5 | 0.70 | 6.00 | 0.8 | 5.2 | ±1 | 0.35 |
PST893R | 6.5 | 0.70 | 6.00 | 0.8 | 5.2 | ±1 | 0.35 |
PST894B | 7.0 | 0.95 | 6.50 | 1.6 | 5.2 | ±1 | 0.35 |
PST893B | 7.0 | 0.95 | 6.50 | 1.6 | 5.2 | ±1 | 0.35 |
PST89EA | 7.0 | 0.95 | 6.50 | 1.2 | 5.2 | ±1 | 0.35 |
PST89DA | 7.0 | 0.95 | 6.50 | 1.2 | 5.2 | ±1 | 0.35 |
PST894A | 7.0 | 0.95 | 6.50 | 1.2 | 5.2 | ±1 | 0.35 |
PST893A | 7.0 | 0.95 | 6.50 | 1.2 | 5.2 | ±1 | 0.35 |
IC-PST84 | 12.0 | 0.70 | 10.00 | 0.8 | 6.0 | ±0.5 | 0.35 |
IC-PST83 | 12.0 | 0.70 | 10.00 | 0.8 | 6.0 | ±0.5 | 0.35 |
PST122D | 40.0 | 2.70 | 20.00 | 5.0 | 10.0 | ±2 | 3.70 |
PST122C | 40.0 | 3.70 | 20.00 | 5.0 | 10.0 | ±2 | 3.00 |
PST122B | 40.0 | 3.00 | 20.00 | 5.0 | 10.0 | ±2 | 3.00 |
PST122A | 40.0 | 2.70 | 20.00 | 5.0 | 10.0 | ±2 | 2.70 |
PST852A | 12.0 | 0.70 | 10.00 | 0.8 | 6.0 | ±0.5 | 0.35 |
PST851A | 12.0 | 0.70 | 10.00 | 0.8 | 6.0 | ±0.5 | 0.35 |
IC-PST86 | 7.0 | 0.95 | 6.50 | 1.2 | 5.2 | ±1 | 0.25 |
IC-PST82 | 12.0 | 0.70 | 10.00 | 0.8 | 6.0 | ±0.5 | 0.25 |
IC-PST81 | 12.0 | 0.70 | 10.00 | 0.8 | 6.0 | ±0.5 | 0.25 |
Power Supply IC > Shunt Regulator
Series name | Associated Data | Absolute maximum rating | Cathode to Anode voltage Min. [V] |
Cathode to Anode voltage Max. [V] |
Cathode current Min. [mA] |
Cathode current Max. [mA] |
Reference voltage Typ. [V] |
Reference voltage accuracy Typ. [%] |
Minimum cathode current Typ. [mA] |
Off-state cathode current Typ. [μA] |
Dynamic impedance Typ. [Ω] |
Package |
---|---|---|---|---|---|---|---|---|---|---|---|---|
MM1530JN | PDF product catalog | 13 | VREF | 12 | 0.08 | 30 | 1.240 | ±0.5 | 0.05 | 0.1 | 0.2 | SOT-23A |
MM1530EN | PDF product catalog | 12 | VREF | 12 | 0.30 | 15 | 1.270 | ±0.8 | 0.15 | 0.1 | 0.4 | SOT-23A |
MM1530DN | PDF product catalog | 12 | VREF | 12 | 0.30 | 30 | 1.240 | ±0.5 | 0.15 | 0.1 | 0.2 | SOT-23A |
MM1530DU | PDF product catalog | 12 | VREF | 12 | 0.30 | 30 | 1.250 | ±0.8 | 0.15 | 0.1 | 0.4 | SC-82ABB |
MM1530CU | PDF product catalog | 12 | VREF | 12 | 0.30 | 15 | 1.270 | ±0.8 | 0.15 | 0.1 | 0.4 | SC-82ABB |
MM1431GN | PDF product catalog | 35 | VREF | 35 | 0.60 | 50 | 2.495 | ±0.8 | 0.30 | 0.1 | 0.4 | SOT-23A |
MM1431FN | PDF product catalog | 35 | VREF | 35 | 0.60 | 50 | 2.495 | ±0.5 | 0.30 | 0.1 | 0.4 | SOT-23A |
MM1431EN | PDF product catalog | 35 | VREF | 35 | 0.60 | 50 | 2.495 | ±0.8 | 0.30 | 0.1 | 0.4 | SOT-23A |
MM1431DN | PDF product catalog | 35 | VREF | 35 | 0.60 | 50 | 2.495 | ±0.4 | 0.30 | 0.1 | 0.4 | SOT-23A |
MM1431DU | PDF product catalog | 35 | VREF | 35 | 0.60 | 50 | 2.495 | ±0.4 | 0.30 | 0.1 | 0.4 | SC-82ABB |
MM1431CU | PDF product catalog | 35 | VREF | 35 | 0.60 | 50 | 2.495 | ±0.8 | 0.30 | 0.1 | 0.4 | SC-82ABB |
Power Supply IC > Linear regulator (LDO)
Series name | Output current [mA] |
Absolute maximum rating [V] |
Recommended operating voltage Min. [V] |
Recommended operating voltage Max. [V] |
Output voltage Min. [V] |
Output voltage Max. [V] |
Output voltage accuracy [%] |
No-Load Input Current [μA] |
Dropout Voltage [V] |
PSRR [dB] |
Output capacitor [μF] |
---|---|---|---|---|---|---|---|---|---|---|---|
MM4066 | 200 | 7.0 | 1.70 | 6.0 | 1.20 | 5.00 | ±1.0 | 7.5 | 0.35 | 50 | |
MM4047 | 450 | 6.0 | 2.20 | 5.5 | 1.80 | 4.50 | ±2.0 | 14.0 | 0.16 | 80 | 2.20 |
MM3871 | 300 | 7.0 | 2.00 | 6.5 | 1.00 | 5.00 | ±1.0 | 25.0 | 0.62 | 70 | 0.47 |
MM3866 | 200 | 7.0 | 1.70 | 6.0 | 1.20 | 5.00 | ±1.0 | 0.9 | 0.35 | 50 | |
MM3864 | 300 | 7.0 | 2.00 | 6.5 | 1.00 | 5.00 | ±1.0 | 20.0 | 0.24 | 75 | 1.00 |
MM3847 | 250 | 6.0 | 2.20 | 5.5 | 1.20 | 4.50 | ±2.0 | 14.0 | 0.09 | 80 | 2.20 |
MM3823 | 500 | 7.0 | 1.60 | 6.5 | 1.00 | 5.00 | ±1.0 | 60.0 | 0.25 | 65 | 1.00 |
MM3816 | 200 | 6.5 | 1.70 | 5.5 | 1.00 | 5.00 | ±1.0 | 42.0 | 0.30 | 75 | 1.00 |
MM3764 | 200 | 7.0 | 1.60 | 6.5 | 0.80 | 5.00 | ±1.0 | 20.0 | 0.08 | 75 | 1.00 |
MM3763 | 200 | 7.0 | 1.80 | 6.5 | 0.80 | 5.00 | ±1.0 | 25.0 | 0.40 | 70 | 0.47 |
MM3755 | 150 | 7.0 | 1.70 | 6.0 | 1.20 | 5.00 | ±0.8 | 0.9 | 0.28 | 50 | 0.10 |
MM3703 | 1000 | 7.0 | 1.60 | 6.5 | 1.00 | 5.00 | ±1.0 | 60.0 | 0.46 | 65 | 1.00 |
MM3702 | 1000 | 7.0 | 1.60 | 6.5 | 1.00 | 5.00 | ±1.0 | 60.0 | 0.46 | 65 | 1.00 |
MM3615 | 300 | 7.0 | 1.80 | 6.5 | 0.80 | 5.00 | ±1.0 | 90.0 | 0.24 | 70 | 1.00 |
MM3608 | 300 | 7.0 | 1.80 | 6.5 | 0.80 | 5.00 | ±1.0 | 90.0 | 0.24 | 70 | 1.00 |
MM3571 | 300 | 7.0 | 2.00 | 6.5 | 1.00 | 5.00 | ±1.0 | 25.0 | 0.62 | 70 | 0.47 |
MM3566 | 200 | 7.0 | 1.70 | 6.0 | 1.20 | 5.00 | ±1.0 | 0.9 | 0.35 | 50 | |
MM3534 | 150 | 7.0 | 1.70 | 6.0 | 1.20 | 5.00 | ±0.8 | 0.9 | 0.28 | 50 | 0.10 |
MM3532T | 150 | 7.0 | 1.60 | 6.0 | 1.20 | 5.00 | ±1.0 | 50.0 | 0.13 | 70 | 1.00 |
MM3532A | 500 | 6.5 | 1.60 | 6.0 | 1.20 | 5.00 | ±1.0 | 50.0 | 0.07 | 70 | 1.00 |
MM3529 | 1000 | 6.5 | 1.60 | 6.0 | 1.20 | 5.00 | ±1.0 | 50.0 | 0.50 | 70 | 1.00 |
MM3526 | 500 | 6.5 | 1.60 | 6.0 | 1.20 | 5.00 | ±1.0 | 50.0 | 0.25 | 70 | 1.00 |
MM3479 | 1000 | 6.5 | 1.60 | 6.0 | 1.20 | 5.00 | ±1.0 | 50.0 | 0.50 | 70 | 1.00 |
MM3478 | 500 | 6.5 | 1.60 | 6.0 | 1.20 | 5.00 | ±1.0 | 50.0 | 0.25 | 70 | 1.00 |
MM3464 | 300 | 7.0 | 2.00 | 6.5 | 1.00 | 5.00 | ±1.0 | 20.0 | 0.24 | 75 | 1.00 |
MM3416 | 200 | 6.5 | 1.70 | 5.5 | 1.00 | 5.00 | ±1.0 | 42.0 | 0.30 | 75 | 0.47 |
MM3411 | 200 | 7.0 | 1.80 | 6.5 | 0.80 | 5.00 | ±1.0 | 25.0 | 0.40 | 70 | 0.47 |
MM3404 | 200 | 7.0 | 1.60 | 6.5 | 0.80 | 5.00 | ±1.0 | 20.0 | 0.08 | 75 | 1.00 |
MM3376 | 150 | 6.5 | 1.10 | 6.0 | 0.80 | 5.00 | ±2.0 | 1.7 | 0.05 | 0.10 | |
MM312x | 250 | 12.0 | 10.0 | 1.80 | 6.00 | ±2.0 | 1.0 | 0.40 | 0.10 | ||
MM1998 | 200 | -12.0 | -10.00 | -2.0 | -5.00 | -1.10 | ±1.0 | 160.0 | 0.50 | 70 | 1.00 |
MM1937 | 300 | 16.0 | 6.50 | 14.0 | 3.00 | 10.00 | ±2.0 | 300.0 | 0.30 | 70 | 2.20 |
MM1936 | 100 | 16.0 | 3.40 | 14.0 | 3.00 | 8.00 | ±2.0 | 400.0 | 0.20 | 70 | 2.20 |
MM1926 | 250 | 16.0 | 2.50 | 14.0 | 3.00 | 10.00 | ±2.0 | 200.0 | 0.20 | 70 | 2.20 |
MM1920 | 150 | 6.5 | 1.10 | 6.0 | 0.40 | 1.50 | 170.0 | 65 | 1.00 | ||
MM1899 | 300 | 15.0 | 2.00 | 14.0 | 1.50 | 5.40 | ±1.0 | 140.0 | 0.35 | 70 | 1.00 |
MM1898 | 200 | -12.0 | -10.00 | -2.0 | -5.00 | -0.90 | ±1.0 | 160.0 | 0.50 | 70 | 1.00 |
MM1890 | 300 | 16.0 | 9.00 | 14.0 | 8.00 | 10.00 | ±2.0 | 75.0 | 0.45 | 60 | 1.00 |
MM1886 | 300 | 16.0 | 1.80 | 14.0 | 1.50 | 5.00 | ±2.0 | 75.0 | 0.45 | 70 | 1.00 |
MM1877 | 1000 | 15.0 | 2.20 | 14.0 | 1.50 | 5.00 | ±2.0 | 2000.0 | 0.25 | 70 | 1.00 |
MM1870 | 1500 | 12.0 | 1.20 | 10.0 | 0.90 | 5.00 | ±2.0 | 1000.0 | 0.26 | 65 | 1.00 |
MM1868 | 1000 | 12.0 | 1.15 | 10.0 | 0.90 | 2.00 | ±2.0 | 1000.0 | 0.18 | 65 | 1.00 |
MM1866 | 1000 | 12.0 | 2.20 | 10.0 | 1.50 | 5.00 | ±2.0 | 2500.0 | 0.20 | 65 | 1.00 |
MM1856 | 200 | 15.0 | 1.80 | 14.0 | 1.50 | 5.00 | ±2.0 | 75.0 | 0.30 | 70 | 1.00 |
MM1849 | 300 | 16.0 | 9.00 | 14.0 | 8.00 | 10.00 | ±2.0 | 75.0 | 0.45 | 60 | 1.00 |
MM1839 | 200 | 16.0 | 1.80 | 14.0 | 1.50 | 5.00 | ±2.0 | 85.0 | 0.30 | 70 | 1.00 |
MM1836 | 200 | 15.0 | 1.80 | 14.0 | 1.50 | 5.00 | ±2.0 | 75.0 | 0.30 | 70 | 1.00 |
Analog-to-digital convertor / Analog Front End IC > Analog Front End IC
Analog Front End IC
Parts | Number of input channels [ch] |
Resolution [bit] |
Package | |
---|---|---|---|---|
MM3609ARRE | Resistance 2CH | 24 | PLP-24 | PDF product catalog |
Analog-to-digital convertor / Analog Front End IC > Analog to Digital Converter IC
SAR type analog-to-digital converter IC
Delta Sigma ADC
Power Semiconductor > IGBT (Insulated Gate Bipolar Transistor)
MR sereis IGBT middle current range
Parts | Associated Data | Gate-Emitter voltage VCES [V] |
Collector current IC [A] |
Collector-Emitter saturation voltage VCE(sat) @Tj=25deg C typical limit [V] |
Collector-Emitter saturation voltage VCE(sat) @Tj=25deg C upper limit [V] |
Gate Voltage VGES [V] |
Gate-Emitter threshold voltage VGE(th) lower limit [V] |
Gate-Emitter threshold voltage VGE(th) upper limit [V] |
Die size X [mm] |
Die size Y [mm] |
Junction temperature Tj [deg.C] |
---|---|---|---|---|---|---|---|---|---|---|---|
MMJC5B0A01xx | PDF product catalog | 1250 | 200 | 1.85 | 2.15 | -30~30 | 5.00 | 6.80 | 11.90 | 11.90 | -40~175 |
MMJC5A5A01xx | PDF product catalog | 1250 | 150 | 1.85 | 2.15 | -30~30 | 5.00 | 6.80 | 10.50 | 10.50 | -40~175 |
MMJC5A0A01xx | PDF product catalog | 1250 | 100 | 1.85 | 2.15 | -30~30 | 5.00 | 6.80 | 8.80 | 8.80 | -40~175 |
MMJC575A01xx | PDF product catalog | 1250 | 75 | 1.85 | 2.15 | -30~30 | 5.00 | 6.80 | 7.90 | 7.90 | -40~175 |
MMJ65B0A02xx | PDF product catalog | 650 | 200 | 1.30 | 1.60 | -30~30 | 5.00 | 6.80 | 10.60 | 10.60 | -40~175 |
MMJ65A5A02xx | PDF product catalog | 650 | 150 | 1.30 | 1.60 | -30~30 | 5.00 | 6.80 | 9.30 | 9.30 | -40~175 |
MMJ65A0A02xx | PDF product catalog | 650 | 100 | 1.30 | 1.60 | -30~30 | 5.00 | 6.80 | 7.80 | 7.80 | -40~175 |
MMJ65B0A00xx | PDF product catalog | 650 | 200 | 1.50 | 1.80 | -30~30 | 5.00 | 6.80 | 10.60 | 10.60 | -40~175 |
MMJ65A5A00xx | PDF product catalog | 650 | 150 | 1.50 | 1.80 | -30~30 | 5.00 | 6.80 | 9.30 | 9.30 | -40~175 |
MMJ65A0A00xx | PDF product catalog | 650 | 100 | 1.50 | 1.80 | -30~30 | 5.00 | 6.80 | 7.80 | 7.80 | -40~175 |
MI sereis IGBT middle current range
Parts | Associated Data | Gate-Emitter voltage VCES [V] |
Collector current IC [A] |
Collector-Emitter saturation voltage VCE(sat) @Tj=25deg C typical limit [V] |
Collector-Emitter saturation voltage VCE(sat) @Tj=25deg C upper limit [V] |
Gate Voltage VGES [V] |
Gate-Emitter threshold voltage VGE(th) lower limit [V] |
Gate-Emitter threshold voltage VGE(th) upper limit [V] |
Internal gate rasistor Rgint typical limit [Ω] |
Die size X [mm] |
Die size Y [mm] |
Junction temperature Tj [deg.C] |
---|---|---|---|---|---|---|---|---|---|---|---|---|
MMJC0B0G00xx | PDF product catalog | 1200 | 200 | 1.95 | 2.30 | -30~30 | 5.20 | 6.60 | 3.3 | 16.00 | 12.00 | -40~175 |
MMJC0A5G00xx | PDF product catalog | 1200 | 150 | 1.95 | 2.30 | -30~30 | 5.20 | 6.60 | 5.0 | 12.36 | 11.40 | -40~175 |
MMJC0A0G00xx | PDF product catalog | 1200 | 100 | 1.95 | 2.30 | -30~30 | 5.20 | 6.60 | 7.5 | 10.26 | 9.60 | -40~175 |
MMJC075G00xx | PDF product catalog | 1200 | 75 | 1.95 | 2.30 | -30~30 | 5.20 | 6.60 | 10.0 | 9.00 | 7.80 | -40~175 |
MMJC050G00xx | PDF product catalog | 1200 | 50 | 1.95 | 2.30 | -30~30 | 5.20 | 6.60 | 4.0 | 7.18 | 6.80 | -40~175 |
MMJC5B0F00xx | PDF product catalog | 1250 | 200 | 1.65 | 1.95 | -30~30 | 5.00 | 6.80 | 3.3 | 16.00 | 12.00 | -40~175 |
MMJC5A5F00xx | PDF product catalog | 1250 | 150 | 1.65 | 1.95 | -30~30 | 5.00 | 6.80 | 5.0 | 12.36 | 11.40 | -40~175 |
MMJC5A0F00xx | PDF product catalog | 1250 | 100 | 1.65 | 1.95 | -30~30 | 5.00 | 6.80 | 7.5 | 10.26 | 9.60 | -40~175 |
MMJC575F00xx | PDF product catalog | 1250 | 75 | 1.65 | 1.95 | -30~30 | 5.00 | 6.80 | 10.0 | 9.00 | 7.80 | -40~175 |
MMJC550F00xx | PDF product catalog | 1250 | 50 | 1.65 | 1.95 | -30~30 | 5.00 | 6.80 | 4.0 | 7.18 | 6.80 | -40~175 |
MMJ65B0G00xx | PDF product catalog | 650 | 200 | 1.90 | 2.25 | -30~30 | 5.20 | 6.60 | 1.7 | 10.20 | 9.70 | -40~175 |
MMJ65A5G00xx | PDF product catalog | 650 | 150 | 1.90 | 2.25 | -30~30 | 5.20 | 6.60 | 1.7 | 7.90 | 9.70 | -40~175 |
MMJ65A0G00xx | PDF product catalog | 650 | 100 | 1.90 | 2.25 | -30~30 | 5.20 | 6.60 | 1.7 | 9.00 | 6.00 | -40~175 |
MMJ6575G00xx | PDF product catalog | 650 | 75 | 2.00 | 2.35 | -30~30 | 5.20 | 6.60 | 1.7 | 6.60 | 5.90 | -40~175 |
MMJ65B0F00xx | PDF product catalog | 650 | 200 | 1.45 | 1.75 | -30~30 | 5.20 | 6.60 | 1.7 | 10.20 | 9.70 | -40~175 |
MMJ65A5F00xx | PDF product catalog | 650 | 150 | 1.45 | 1.75 | -30~30 | 5.20 | 6.60 | 1.7 | 7.90 | 9.70 | -40~175 |
MMJ65A0F00xx | PDF product catalog | 650 | 100 | 1.45 | 1.75 | -30~30 | 5.20 | 6.60 | 1.7 | 6.00 | 9.00 | -40~175 |
MMJ6575F00xx | PDF product catalog | 650 | 75 | 1.55 | 1.85 | -30~30 | 5.20 | 6.60 | 1.7 | 6.60 | 5.90 | -40~175 |
MMJ6545G00xx | PDF product catalog | 650 | 45 | 2.00 | 2.35 | -30~30 | 5.20 | 6.60 | 4.98 | 4.98 | -40~175 | |
MMJ6545F00xx | PDF product catalog | 650 | 45 | 1.55 | 1.85 | -30~30 | 5.20 | 6.60 | 4.98 | 4.98 | -40~175 |
Power Semiconductor > FRD (Fast Recovery Diode)
MR Series FRD
Parts | Associated Data | Reverse voltage VRR [V] |
Forward current IF [A] |
Forward voltage VF typical limit [V] |
Forward voltage VF upper limit [V] |
Die size X [mm] |
Die size Y [mm] |
Junction temperature Tj [deg.C] |
---|---|---|---|---|---|---|---|---|
MMKC5B0A00xx | PDF product catalog | 1250 | 200 | 2.10 | 2.60 | 9.30 | 9.30 | -40~175 |
MMKC5A5A00xx | PDF product catalog | 1250 | 150 | 2.10 | 2.60 | 8.20 | 8.20 | -40~175 |
MMKC5A0A00xx | PDF product catalog | 1250 | 100 | 2.10 | 2.60 | 6.80 | 6.80 | -40~175 |
MMKC575A00xx | PDF product catalog | 1250 | 75 | 2.10 | 2.60 | 5.80 | 5.80 | -40~175 |
MMK65B0A00xx | PDF product catalog | 650 | 200 | 1.70 | 2.20 | 7.00 | 7.00 | -40~175 |
MMK65A5A00xx | PDF product catalog | 650 | 150 | 1.70 | 2.20 | 6.00 | 6.00 | -40~175 |
MMK65A0A00xx | PDF product catalog | 650 | 100 | 1.70 | 2.20 | 5.00 | 5.00 | -40~175 |
MI Series FRD
Parts | Associated Data | Reverse voltage VRR [V] |
Forward current IF [A] |
Forward voltage VF typical limit [V] |
Forward voltage VF upper limit [V] |
Die size X [mm] |
Die size Y [mm] |
Junction temperature Tj [deg.C] |
---|---|---|---|---|---|---|---|---|
MMKC5B0FA0xx | PDF product catalog | 1250 | 200 | 1.70 | 2.10 | 12.10 | 8.70 | -40~175 |
MMKC5B0F00xx | PDF product catalog | 1250 | 200 | 1.70 | 2.10 | 14.20 | 6.70 | -40~175 |
MMKC5A5F00xx | PDF product catalog | 1250 | 150 | 1.70 | 2.10 | 10.80 | 6.80 | -40~175 |
MMKC5A0F00xx | PDF product catalog | 1250 | 100 | 1.70 | 2.10 | 8.40 | 6.10 | -40~175 |
MMKC575F00xx | PDF product catalog | 1250 | 75 | 1.70 | 2.10 | 7.30 | 5.40 | -40~175 |
MMKC550F00xx | PDF product catalog | 1250 | 50 | 1.70 | 2.10 | 6.30 | 4.50 | -40~175 |
MMK65B0F00xx | PDF product catalog | 650 | 200 | 1.45 | 1.85 | 9.70 | 5.20 | -40~175 |
MMK65A5F00xx | PDF product catalog | 650 | 150 | 1.45 | 1.85 | 7.80 | 4.90 | -40~175 |
MMK65A0F00xx | PDF product catalog | 650 | 100 | 1.45 | 1.85 | 7.00 | 3.80 | -40~175 |
MMK6575F00xx | PDF product catalog | 650 | 75 | 1.45 | 1.85 | 5.40 | 3.80 | -40~175 |
Sensors
Semiconductor Sensor > Temperature Switch IC
Parts | Outline | Operating Supply Voltage lower limit [V] |
Operating Supply Voltage upper limit [V] |
Operating Ambient Temperature lower limit [deg.C] |
Operating Ambient Temperature upper limit [deg.C] |
Detecting Temperature Accuracy lower limit [deg.C] |
Detecting Temperature Accuracy upper limit [deg.C] |
Supply current Typ. [μA] |
---|---|---|---|---|---|---|---|---|
MM3688 | The MM3688 series has a detection temperature of + 60 ° C ≤ TDET ≤ + 90 ° C, and is being developed in steps of 1.0 ° C. This product achieves an ultra-low current consumption of 0.12 μA typ., Which is ideal for mobile products that are concerned about power consumption. |
1.6 | 5.0 | -40 | 125 | -2 | 2 | 0.12 |
MM3588 | The MM3588 series has a detection temperature of + 60 ° C ≤ TDET ≤ + 90 ° C, and is being developed in steps of 1.0 ° C. This product has a control terminal (CE terminal) for turning the output on and off. |
1.6 | 5.0 | -30 | 125 | -2 | 2 | 1.50 |
MM3488 | The MM3488 series has a detection temperature in the range of high temperature detection type: + 25 ° C ≤ TDET ≤ + 90 ° C, low temperature detection type: -20 ≤ TDET ≤ + 24 ° C. We are developing products in steps of 1.0 ° C. |
1.6 | 5.0 | -30 | 105 | -2 | 2 | 1.50 |
Semiconductor Sensor > Analog Temperature sensor IC
Parts | Operating Supply Voltage lower limit [V] |
Operating Supply Voltage upper limit [V] |
Operating Ambient Temperature lower limit [deg.C] |
Operating Ambient Temperature upper limit [deg.C] |
Detecting Temperature Accuracy lower limit [deg.C] |
Detecting Temperature Accuracy upper limit [deg.C] |
Temperature sensitivity [mV/°C] |
Load Regulation(0~200μA) [mV] |
Package | Package2 |
---|---|---|---|---|---|---|---|---|---|---|
MM3154 | 2.4 | 6.5 | -40 | 100 | -2.5 | 2.5 | -8.2 | 0~1.0 | SC-82ABB | SSON-4B |
Semiconductor Sensor > Digital Temperature sensor IC
Parts | Resolution(1) [deg.C] |
Resolution(2) [bit] |
Data Update time [ms] |
Operating Voltage lower limit [V] |
Operating Voltage upper limit [V] |
Ambient operating temperature lower limit [deg.C] |
Ambient operating temperature upper limit [deg.C] |
Package | Package2 |
---|---|---|---|---|---|---|---|---|---|
MM3286 | 0.5 | 9 | 2 | 3 | 5.5 | -40 | 125 | SOP-8D | |
MM3285 | 0.5 | 9 | 2 | 3 | 5.5 | -40 | 125 | SOT-26A | SOT-25A |
Semiconductor Sensor > 6-axis force torque sensor
ProductName | Associated Data | Power Supply [V] |
Operating Temperature Range [deg.C] |
Load rating (Force) [N] |
Load rating (Moment) [N・m] |
Accuracy [%F.S.] |
Interface | Package Size [mm] | Weight [g] |
---|---|---|---|---|---|---|---|---|---|
MMS101 | PDF product catalog | VDD:3.8~14.0V/ VDDIO:1.14~3.6V |
5~45 | ±40 | ±0.4 | ±5 | SPI | Φ9.6 × 9.0 | 3g |
Sensing Devices
Load cell > Compression type for industrial weighing systems
Parts | External view | Features | Rated capacity |
---|---|---|---|
Beam type load cell CBC1-※ series | ![]() |
Suitable for the weighing systems of which mounting space is limited. | 49.03 N {5 kgf}~19.61 kN {2 tf} |
Low profile shear-web type CWV1-※ series | ![]() |
Shear-web type structure and strong in lateral load. | 19.61 kN {2 tf}~980.7 kN {100 tf} |
High overload capacity compression type CCR1(B)-※ series | ![]() |
Canister type load cell with safe overload capacity. | 4.903 kN {500 kgf}~196.1 kN {20 tf} |
Explosion-proof canister type load cell CCP1-※-Z series | ![]() |
Suitable for high explosion risk envitonment such as with flammable liquid or gas. | 1.961 kN {200 kgf}~196.1 kN {20 tf} |
Accurate canister type load cell CCP1(A)-※ series | ![]() |
Ideal for the weighing system of hopper & tank scales, etc. | 490.3 N {50 kgf}~196.1 kN{20 tf} |
Accurate compression type load cell CMP1-※ series | ![]() |
Precise low profile load cell with all stainless steel structure. | 2.452 kN {250 kgf}~196.1 kN {20 tf} |
Compact size compression type load cell CMM1J-※ series | ![]() |
Compact size, light weight load cell with all stainless steel construction. | 490.3 N {50 kgf}~19.61 kN {2 tf} |
Compact size compression type load cell CMM1R-※ series | ![]() |
Compact size, light weight load cell with all stainless steel construction. | 490.3 N {50 kgf}~19.61 kN {2 tf} |
Beam type load cell CBE1- ※ series (General Spec.) | ![]() |
Beam type load cell with all stainless structure. | 49.03 N {5 kgf}~1.961 kN {200 kgf} |
Beam type accurate load cell CBE1-C3- ※ series (OIML spec.) | ![]() |
Beam type load cell with all stainless structure. Rated capacity : CBE1-C3 (OIML standard) 5 kg ~ 200 kg |
10kg~200kg |
Square beam type load cell C2B1B-※ series (General Spec.) | ![]() |
Ideal for weighing system of floor / tank / hopper scale. | 200 kg (1.961 kN) ~ 2 ton (19.61 kN) |
Square beam type load cell C2B1B-*-C3 series (OIML spec.) | ![]() |
Ideal for weighing system of floor / tank / hopper scale. Available for OIML R60 Class C3 certified model. C2B1B (General Spec.) 200 kg {1.961 kN} ~ 2 t {19.61 kN} |
200kg~2t |
Square beam type load cell C3B1-*-NS series (General spec.) | ![]() |
Ideal for the measuring system of floor scale, tank scale and hopper. | 1.961 kN {200 kgf}~49.03 kN {5 tf} |
Square beam type accurate load C3B1-* series (OIML spec.) | ![]() |
Ideal for the measuring system of floor scale, tank scale and hopper. Available for OIML R60 Class C4 certified model. |
200kg~5t |
Double convex type compression service load cell CC010 series (General spec.) | ![]() |
Double convex mechanism. All stainless steel hermetic sealed structure. | 4.903 kN {500 kgf}~490.3 kN{50 tf} |
Double convex type compression service load cell CC010-C3 series (OIML spec.) | ![]() |
Double convex mechanism. All stainless steel hermetic sealed structure. Available for OIML R60 Class C3 certified model. |
2t~50t |
Load cell > For commercial scale
Parts | External view | Outline | Rated capacity |
---|---|---|---|
Middle capacity scale for commercial scale | ![]() |
Applied for multi-point method platform scale. | 2.942 kN{300 kgf}~68.65 kN{7 tf} |
For commercial scale C2D1-* General standard | ![]() |
Available to multi-point application. Approved OIML R60 Class C4. | 100kg~800kg |
For commercial scale U2D1-* General standard | ![]() |
Middle capacity for electrical scale. | 29.42 N{3 kgf}~980.7 N{100 kgf} |
For commercial scale U2D1-*-C3 OIML standard | ![]() |
Middle capacity for electrical scale. OIML R60 certification | 6kg~25kg |
For commercial scale CB14-*-21 General standard | ![]() |
Suitable for health meter. | 980.7 N{100 kgf}~4.903 kN{500 kgf} |
For commercial scale CB14-*-C6 OIML standard | ![]() |
Suitable for health meter. OIML R60 certification. | 100kg~500kg |
Middle capacity for commercial scale (General spec) CB004S-* General standard | ![]() |
Middle capacity stainless steel construction, | 98.07 N{10 kgf}~980.7 N{100 kgf} |
For commercial scale CB004S-*-C3 OIML standard | ![]() |
Middle capacity stainless steel construction, OIML R60 certification. | 10kg~100kg |
Middle capacity for commercial scale CB004-* General standard | ![]() |
Middle capacity for electrical scale. | 98.07 N{10 kgf}~980.7 N{100 kgf} |
Middle capacity for commercial scale CB004-*-C4/-C6 OIML standard | ![]() |
Middle capacity for electrical scale. OIML R60 certification. | 10kg~100kg |
Middle capacity for commercial scale C2G1-*-A-C6 OIML standard | ![]() |
Middle capacity for electrical scale. OIML R60 certification. | 6kg~50kg |
Load cell > For special application
Parts | External view | Outline | Rated capacity |
---|---|---|---|
Load beam bending type U3C1-B | ![]() |
Suitable for the weighing systems of which mounting space is limited. | 49.03 N {5 kgf}~980.7 N {100 kgf} |
Small capacity bending beam type UTA | ![]() |
The rated capacity is little higher than the UL series'. | 980.7 mN {100 gf}~19.61 N {2 kgf} |
Small capacity bending beam type UL/ULA | ![]() |
Excellent in small force measurement such as tension of yarn. | 19.61 mN {2 gf}~980.7 mN {100 gf} |
Centre hole type C1W1M | ![]() |
Developed for injection molding machines. | 58.84 kN {6 tf}~490.3 kN {50 tf} |
Miniature type LSMS | ![]() |
Miniture type load cell with 5 mm at height and 7 mmat diameter. | 196.1 N {20 kgf}~490.3 N {50 kgf} |
Miniature type LSM - B | ![]() |
12mm~21mm of diameter and suitable for use where space is limited. | 4.903 N {500 gf}~19.61 kN {2 tf} |
Miniature type CM085 | ![]() |
High accurate, compact and thin type compression service load cell with stopper. | 2 N ~ 2 kN |
Low profile shear-web type UWV1 | ![]() |
Shear-web type structure and strong in lateral load. | 19.61 kN {2 tf}~980.7 kN {100 tf} |
Load cell > Force Sensor
Parts | Product image | Features |
---|---|---|
CF059 series | ![]() |
Stainless steel, and full bridge type Rated capacity : 1.961 N {0.2 kgf} ~ 39.22 N {4 kgf} |
CF054 series | ![]() |
Aluminum roberval method sensor, full bridge type Rated capacity : 0.294 kN {30 kgf} ~ 1.961 kN {200 kgf} |
FSV series | ![]() |
Aluminum element, Roverval method sensor, full bridge type Rated capacity : 0.981 N{100 gf} ~ 2.942 N {300 gf} |
FSU series | ![]() |
Aluminum alloy. Roverbal type and full bridge type Rated capacity : 4.903 N {0.5 kgf}~147.1 N {15 kgf} |
FSI series | ![]() |
Aluminum alloy. Full bridge type. Rated capacity : 19.61 N {2 kgf}~196.1 N {20 kgf} |
FSA series | ![]() |
Stainless steel. 2 type of half bridge type and full bridge type. Rated capacity : 22.24 N{5 lb} ~ 177.9 N {40 lb} |
Digital Indicator
Parts | Product image | Outline | Non-linearity [%F.S.] |
Sampling speed [times/s] |
I/O icon |
---|---|---|---|---|---|
PR5410 Process Indicator | ![]() |
●PR5410 is a weighing module that achieves 10000e Class Ⅲ level accuracy ●High speed conversion enables response times from 10 ms ●A 10/100 Mbits/s LAN adapter is built in ●Load cell,control input/output optocoupler,LAN adapter connector and RS232C interfaces are mounted on the back panel ●Enables actual load adjustment using weights,calibration of numerical input in mV/V,and load cell date input(smart calibration) ●Large display(height 18mm),cleary visible backlight LCD display ●OIML R76 10,000e ●Internal resolution:1/4,000,000 |
|||
PC Software for communication with Digital Indicator | ![]() |
Easier to set a digital indicator with PC. The parameter of a digital indicator can be managed with PC. | |||
Digital Moment limitter DML-802C | ![]() |
The hanging load and the operating radius are displayed and the alarm has been output. Japan Crane Association accepted product. | 2 | ||
Digital indicator model TMD-100 for tension meter system | ![]() |
Space saving instrument combines multiple system functions in system control panel to conserve wiring, and miniaturize the control panel. | 0.01 | 100 | ![]() |
Digital indicator for digital load cell CSD-401 | ![]() |
Digital indicator for digital load cell. Compact size. Equipped with RS-232C as a standard. | 15 | ![]() |
|
PCB type digital indicator CSD-581-15/74 | ![]() |
DC24 V power supply voltage. Broad range of calibration function. CSD-581-15 : BCD digital output, CSD-581-74 : RS-232C interface. |
0.01 | 100 | ![]() |
Digital Peak Holder CSD-819C | ![]() |
Compact size and light weight. High sampling rate (2 000 times/s). Range of peak mode settings. CE mark applied. | 2000 | ![]() |
|
Digital Peak Holder CSD-709 | ![]() |
Compact size and light weight. High sampling rate (4 000 times/s). Waveform display and condition setting by PC. Simplified calibration, Various interface, CE mark applied. | 0.02 | 4000 | ![]() |
Digital indicator CSD-701B | ![]() |
Compact size (48 mm x 96 mm) with peak hold function. BCD output as an option. |
20 | ![]() |
|
Digital Indicator CSD-815B | ![]() |
Conpact size (96 mm x 96 mm) digital indicator for strain gage applied transducer with peak hold function, CC-Link interface and CE mark applied. | 100 | ![]() |
|
Weight conversion module CSD-892B series | ![]() |
High performance and palmtop size. Smart and fit model in FA system. Best for high speed and high resolution application. Equipped with CC-Link interface, RS-232C interface, RS-422/485 interface, current / voltage output and USB 2.0/1.1 interface. Built-in control panel type. CE mark applied.JIS B 7611-2:2015 Annex C (Environmental Test Level H/Level L). |
0.01 | 500 | ![]() |
Built-in control panel type digital indicator CSD-891B | ![]() |
Broad range of computer and sequencer interfaces are included. Correspond to CC-Link. |
0.01 | 200 | ![]() |
Digital indicator CSD-814B | ![]() |
Clear, large fluorescent tube display with 22 mm charactrer height, Ratio of load vs. rated capacity is clearly indicated with 11 dots bar indicator. | 0.01 | 100 | ![]() |
Digital indicator CSD-904-EX | ![]() |
Best for high accuracy (6 000 div.) scale application (More than 5 micro-volts per division minimum input.) Built-in linearizer (up to 3 points) | 0.01 | 15 | ![]() |
Digital Indicator CSD-903-EX | ![]() |
Active standard that succeeds to measurement knowhow cultivated by CSD-912 without regrettably. Controlable in variegated sequence mode. Compact size and light weight. (depth: 136.5 mm), CE mark applied. | 0.01 | 200 | ![]() |
Graphic Digital Indicator CSD-912B-EX | ![]() |
6.2 inches liquid crystal touch panel display with excellent visibility TFT color and wide viewing angle. Waveform display of weighing status. 100 kinds of recipe measurement can be memorized in brand memory. 1000 times/s of high speed A/D conversion. RS-485 / serial interface as a standard function. CE mark applied. | 0.01 | 1000 | ![]() |
