PNN7RB55PW Vibration motor

  • Click the arrow icon in the table below to switch from ascending to descending order.

    scroll

    Model

    Operating Voltage
    lower limit
    [V]

    Operating Voltage
    upper limit
    [V]

    Rated Voltage
    [V]

    Rated Load Speed
    [min-1]

    Rated Load Current
    [mA]

    Shaft Length
    [mm]

    Rated Load
    PNN7RB55PW 2.4 3.6 3.0 7500 70 5.5 weight

  • Associated Data
