SE10G

Click the arrow icon in the table below to switch from ascending to descending order.

scroll

Model	Operating Voltage lower limit [V]	Operating Voltage upper limit [V]	Rated Voltage [V]	No load speed [min-1]	No Load Current [mA]	Rated Load [gf･cm]	Rated Load [mN・m]	Rated Load Speed [min-1]	Rated Load Current [mA]	Starting Torque [gf･cm]	Starting Torque [mN・m]	Starting current [mA]
SE10G0UTM	1.0	5.0	4.0	11100	75.0	5.10	0.50	8520	243	21.90	2.15	801
SE10G0RTM	1.0	5.0	4.0	7703	42.0	4.10	0.40	5651	129	15.30	1.50	368
SE10G0VTM	1.0	4.0	3.0	9641	60.0	4.10	0.40	7556	207	18.40	1.80	738
